Atrump #LH-117-Centroid, 24 automatic tool changer, 43.3" X, 35" Y, 27" Z, 4500 RPM, 3-Axis, 25 HP, 27.6" x49.6" table, new

Manufacturer Atrump
Automatic Tool Changer 24ATC
Longitudinal" X 43.3" X
Cross" Y 35.0" Y
Vertical" Z 27.0" Z
RPM 4500
Stock # SMLH117CENTROID
Price $149,825

For Sale by Sterling Machinery Exchange - New Mach.

Platinum Level Dealer
Surplus Record Dealer Since 1970

Description

DETAILED SPECIFICATION
Table Size27.6" x 49.6"
Load Capacity1,320 Lbs.
Longitudinal Travel43.3"
Cross Travel35.4"
Vertical Head Travel27.6"
Spindle Nose To Table Top4.6" - 32.3"
Spindle Nose to Table Center7.8" - 43.3"
Spindle TaperCAT50/BT50
Spindle Speed4,500 RPM
.
Feed Rates
Rapid Feed RateX: 700 IPM AC, Z: 700 IPM AC, Y: 400 IPM
Cutting Feed Rate1 - 360 IPM
CNC Axis3
ControllerCentroid
Automatic Tool Changer
Number of Tool Stations24 Arm Type
Max. Tool Diameter3.5"
Max. Tool Weight30 Lbs.
Oil Types
CoolantShell Tellus 32
PneumaticAir Tool Oil
WaysMobil Vectra #2
Coolant Capacity36 Gallons
Horsepower25 H.P.
Voltage208V to 230V ~ 3 Phase
Dimensions (W x D x H)117" x 136" x 113"

EQUIPPED WITH
25 H.P. Spindle Motor
BT50/CAT50 Spindle Taper
4,500 rpm Spindle Speed
Heavy Duty 3 Axes Linear Guide Way
Built In Rotary Table
Double Nut Precision Ball Screws Hardened & Ground for High Accuracy/Long Lasting
FC30 Meehanite Casting Main Frame
100% Laser Tested for Positioning Accuracy/Repeatability
Telescopic Steel Way Covers on all 3 Axes
Air Blast, Coolant Flush Gun
Centroid M400 Control with 15" LCD
24 Tools Swing Arm ATC
Anti-Flex Reinforced Base & Column
Tool Box & Tools
Built In Quartz Work Light
Coolant System
Air Blast System
Central Lubrication System
RS-232 Interface
Automatic lubrication system
Full Guarding
Leveling Bolts & Plate
Splash Guard
Halogen Work Light
Shop Floor Programming/Conversational
Operation Manual
