Click to zoom in
For Sale by G-2000
Surplus Record Dealer Since 2011
Location: Toledo, OH
Contact Evan Yoder
Phone Number: 419...> Show Phone Number 419-597-5495
Let the seller know you found their listing on Surplus Record!
Description
MODEL................................: 4A
AREA OF BASE.........................: 76" x 50"
SPINDLE SPEEDS.......................: (36) 10 - 1000 RPM
FEEDS................................: (18) .004 - .125 IPR
THREADS..............................: 8, 11-1/2", 14, 18, 27 TPI
SPINDLE TRAVEL.......................: 18"
SPINDLE DIAMETER.....................: 3-3/16"
TAPER IN SPINDLE.....................: #6 MT
DISTANCE SPINDLE TO BASE.............: 15" MINIMUM to 70" MAXIMUM
DISTANCE SPINDLE TO COLUMN...........: 18" MINIMUM to 72" MAXIUMUM
POWER ELEVATION......................: YES
POWER CLAMPING ON HEAD; ARM..........: YES
POWER HEAD TRAVERSE..................: YES
MOTOR, HORSEPOWER....................: 15 HP
| Specifications | |
| Machine Type... | ...Drills, Radial |
| Manufacturer... | ...CARLTON |
| Model... | ...3A |
| Year... | ...N/A |
| Condition... | ...Used |
| Model... | ...4A |
| Working Surface of Base (T-Slotted)... | ...76 x 50 |
| # Spindle Speeds... | ...36 |
| Spindle Speed Range... | ...10 - 1000 |
| # Feeds... | ...18 |
| Spindle Feeds Range... | ....004 - .125 |
| THREADS... | ...8, 11-1/2, 14, 18, 27 |
| Maximum Spindle Travel... | ...18 |
| Spindle Diameter... | ...3-3/16 |
| Spindle Taper... | ...#6 |
| Min Distance Spindle to Base... | ...15 |
| Max Distance Spindle to Base... | ...70 |
| Min Distance Spindle to Column... | ...18 inches |
| Max Distance Spindle to Column... | ...72 inches |
| POWER ELEVATION... | ...YES |
| POWER CLAMPING ON HEAD; ARM... | ...YES |
| POWER HEAD TRAVERSE... | ...YES |
| Motor Horsepower... | ...15 |
Get Your Price from G-2000!
