For Sale by Wheeler Machinery Sales
Surplus Record Dealer Since 1998
Location: Pomona, CA
Contact Dan Wheeler
Phone Number: 909...> Show Phone Number 909-348-5610
Let the seller know you found their listing on Surplus Record!
$7,950 USD
Description
ISO 9001 certified
American design and Taiwan quality machine
Gang slit from 16Ga to 30Ga
feed the sheet metal from the manual decoiler
3 diameter shafts mounted in precision ball sealed bearings
4 sets of slitting blades with stripper rings to prevent material twisting
Forward and reverse control with electrical cabinet
One year warranty for parts
full length finger guard
Slitting and shearing capacity: width x thickness
mild steel(hot roll) Tensile 60,000PSI 48x16Ga
stainless steel & cold roll, tensile 85,000PSI 48x20Ga
soft aluminum, tensile 28,000PSI 48x12Ga
min. thickness 30Ga
Max. slitting length 20ft
Min. slitting Width 2
Max sheet matel width 49
Shaft for slit blades 3
Infeed/outfeed table height 33-1/2
Slitting blades 4 pairs
Slitting feed speed 57FPM
Slitting capacity: Number of cuts / strips
16Ga mild steel 1 cut / 2 strips
18Ga mild steel 1 cuts / 2 strips
20Ga mild steel 2 cuts / 3 strips
22Ga-24Ga mild steel 3 cuts / 4 strips
26Ga-30Ga mild steel 4 cuts / 5 strips
Slitting motor 1-1/2HP, 110V Amperage draw 18A
Decoiler specifications
manually operated:
For coil size 48 width, 20 coil ID,
Max coil weight 2T = 4,500LBS
Dimensions: 71x32x39-1/2
Machine weight 1012 LBS
Shipping weight 1145 LBS
Machine dimensions LWH 68 x 27 x 47
Shipping dimensions LWH 75 x 34 x 49
American design and Taiwan quality machine
Gang slit from 16Ga to 30Ga
feed the sheet metal from the manual decoiler
3 diameter shafts mounted in precision ball sealed bearings
4 sets of slitting blades with stripper rings to prevent material twisting
Forward and reverse control with electrical cabinet
One year warranty for parts
full length finger guard
Slitting and shearing capacity: width x thickness
mild steel(hot roll) Tensile 60,000PSI 48x16Ga
stainless steel & cold roll, tensile 85,000PSI 48x20Ga
soft aluminum, tensile 28,000PSI 48x12Ga
min. thickness 30Ga
Max. slitting length 20ft
Min. slitting Width 2
Max sheet matel width 49
Shaft for slit blades 3
Infeed/outfeed table height 33-1/2
Slitting blades 4 pairs
Slitting feed speed 57FPM
Slitting capacity: Number of cuts / strips
16Ga mild steel 1 cut / 2 strips
18Ga mild steel 1 cuts / 2 strips
20Ga mild steel 2 cuts / 3 strips
22Ga-24Ga mild steel 3 cuts / 4 strips
26Ga-30Ga mild steel 4 cuts / 5 strips
Slitting motor 1-1/2HP, 110V Amperage draw 18A
Decoiler specifications
manually operated:
For coil size 48 width, 20 coil ID,
Max coil weight 2T = 4,500LBS
Dimensions: 71x32x39-1/2
Machine weight 1012 LBS
Shipping weight 1145 LBS
Machine dimensions LWH 68 x 27 x 47
Shipping dimensions LWH 75 x 34 x 49
Inquire Further with Wheeler Machinery Sales!
