Description
Specifications
Equipped With
Equipped With
| Tonnage Forming | 250 tons |
| Punching | 175 |
| BH (Distance Between Housings) | 10' 5" |
| Bed/Ram Length | 12 feet |
| Below Grade | no |
| Weight | 38000 pounds |
| Top Bed Height | 38 inches |
| Bed Width | 8 inches |
| Throat Depth | 10 inches |
| Ram Stroke (Fully Adjustable) | 8 inches |
| Open Height | 16 inches |
| Closed Height | 8 inches |
| Horsepower | 20 |
| Ram Speeds (In Inches per Minute) | Approach: 102, Press: 16, Return: 132 |
Equipped With
Equipped With
Features:
« All Components Readily Available from Your Local Suppliers
« Groove in Bed and Ram Clamps for American Style Tooling
« Typical 20-30 Year Lifetime
« Full Tonnage throughout Stroke
« Counterbalance for Punching
« Typical +, - .001” Repeatability
« Full Tonnage across Bed and Ram
« 5 Year Parts Warranty
« 5 Year Limited Onsite Labor Warranty
« Lifetime Telephone Support at No Charge
« (2) 24” Work Support Arms
« Manifold centralized lube system
« Hand/Foot sequence w/footswitch
« T-slot across front edge of brake bed
Optional Features:
See PDF attached (May 2026 MODEL AB Press Brake Options--10' 12' and 14' up to AB400-14.pdf)
Delivery:
Approx. 10-12 Weeks
« All Components Readily Available from Your Local Suppliers
« Groove in Bed and Ram Clamps for American Style Tooling
« Typical 20-30 Year Lifetime
« Full Tonnage throughout Stroke
« Counterbalance for Punching
« Typical +, - .001” Repeatability
« Full Tonnage across Bed and Ram
« 5 Year Parts Warranty
« 5 Year Limited Onsite Labor Warranty
« Lifetime Telephone Support at No Charge
« (2) 24” Work Support Arms
« Manifold centralized lube system
« Hand/Foot sequence w/footswitch
« T-slot across front edge of brake bed
Optional Features:
See PDF attached (May 2026 MODEL AB Press Brake Options--10' 12' and 14' up to AB400-14.pdf)
Delivery:
Approx. 10-12 Weeks
