For Sale by AM Industrial
Surplus Record Dealer Since 2006
Location: Brook Park, OH
Contact Brett Wyman
Phone Number: 216...> Show Phone Number 216-433-7171
Let the seller know you found their listing on Surplus Record!
Description
Product Details
Specifications
| Stock Number | AM22408 |
| Brand | Other |
| Capacity | 2.50 inches |
Specifications
2.5” Horn #CNC65TBRE Tube Bender
- Horn Machine Tools CNC 5-Axis heavy duty tube bending machine
- Model: CNC65TBRE
Capacities:
- Maximum Bending Capacity (per mfg. literature):
- Round tube (non-ferrous): 2.50″ OD x .138″ WT
- Round tube (steel): 2.5″ OD x .079″ WT
- Round tube (stainless steel): 2.5″ OD x .055
- Square tube (steel): 1.96″ OD x .079″ WT
- Solid bar (steel): 1.18″
- Maximum degree of bend: 180° + Springback
- Bending Rotation: Right-Hand (Clockwise)
Includes:
- HMT CNC Operator Control – Touchscreen
- Electric servo driven collet (B-axis)
- Electric servo driven bend-arm (C-axis)
- Electric servo driven carriage (Y-axis)
- Hydraulic clamp die
- Pressure die assist
- Mandrel extractor
- Automatic mandrel lubrication
- Automatic tube support
Get Your Price from AM Industrial!
