Description
STOCK NO. 9981
2C FARREL-SYKES HORIZONTAL HERRINGBONE GEAR GENERATOR
S/N 00641 New 1941
SPECIFICATIONS:
Pitch Diameter of Gear Min 0 "
Max 25"
Face Width of Gear Double Helical Min 0"
Max 8"
Straight Tooth Min 0"
Max 5"
Diametral Pitch Helical Min 24 DP
Max 3 DP
Straight Tooth Min 24 DP
Max 2 1/2 DP
Hole in Spindle 3 5/8"
Pitch Dia of Cutters 4"
Floor Space Overall 87 1/2" X 111"
Height Overall 64"
Estimated Weight 13,650 Lbs
Main Drive Motor 5 HP
Coolant Pump Motor 1/2 HP
EQUIPPED WITH:
30 deg Guides
Change Gears
Tooling
Get Your Price from O'Connell Machinery Co!
