Click to zoom in
For Sale by Southern Fabricating Mchy Sales
Surplus Record Dealer Since 2015
Location: Lithia, FL
Contact Dan McCurdy
Phone Number: 813...> Show Phone Number 813-444-4555
Let the seller know you found their listing on Surplus Record!
Description
STANDARD EQUIPMENT:
- Hard-chrome ways
- Front and rear way covers
- Automatic Lube System
Tool Kit includes:
- Machine manual, Half nut wrench, Wrench 17m, 19m, Set of 6 Allen wrenches, Phillip screwdriver, Flat
- Head screw driver, Oil can, Grease Gun, Rear way cover bracket, Pin for indicator, Can of paint.
FULL – FEATURED:
- MILLPWR IS A FULL – FEATURED 2-AXES CONTROL/3-AXES READOUT WITH A NUMBER OF
- SOFTWARE AND HARDWARE FEATURES.
- SOFTWARE
- ABS/INC, POLAR/CARTESIAN, INCH/METRIC.
Programming:
- PROGRAM IN/OUT, POSITION/DRILL, MILL LINES, MILL ARC, BLEND (CORNER RADIUS)
- HOLES (BOLT CIRCLE, RECTANGULAR ARRAY, RECTANGULAR FRAM, LINE),
- CIRCLE (POCKET, FRAM, RING), RECTANGLE (POCKET, FRAME, SLOT, FACING) 9,999 STEPS OF
- PROGRAM SIZE
Special Features:
- CUSTOM POCKETS, REPEAT, ROTATE, MIRROR IMAGE.
- Run Options:
- SINGLE STEP, DRY RUN, GRAPHICS ONLY, MANUAL POSITIONING.
- Calculator Functions:
- GEOMETRY, TRIG.
HARDWARE
- Operator Console: EASY TO USE FORMAT. CONVERSATIONAL ENGLISH. THREE DIMENSIONAL HARD KEYS. 10” FLAT PANEL, COLOR LCD DISPLAY. REMOTE STOP/GO SWITCH.
- Controller Cabinet: HEAVY DUTY ENCLOSURE MODULAR CONSTRUCTION, 1 GHz Intel Celeron MICROPROCESSOR. USB AND RS232 INTERFACE 12.1” HIGH RESOLUTION DISPLAY WITH 3 D GRAPHICS 115VAC – 20 AMPS
- Positioning: PRECISION GLASS SCALE LINEAR ENCODERS. CLOSED LOOP FEEDBACK THROUGH SERVO AMPLIFIERS. DC SERVO MOTORS. PRECISION GROUND BALL SCREWS.
SPECIFICATIONS:
- Table
Working surface 9”X42”
T-slot number, size 3, 5/8”
- Capacity
Table travel; x-axis 25”
Saddle travel; y-axis 11”
Ram travel 12”
Quill travel; z-axis 5”
Knee travel 16”
Spindle to column (nim-max) 6 ¾” – 18 ½”
Spindle to nose to table 2 1/8”-18”
- Spindle
Motor 3 HP
Wiring voltage 220/440V, 3 phase, 60 H
Taper R-8
Speeed (vari speed) 60-4, 500 RPM
Quill feed (IPR) 0.0015, 0.003, 0.006”
Head swivel 360°
Head tilt; right-to-right-left (each way) 45°
Head tilt; up-and-down (each way) 45°
Dimensions and Weight
Floor area (w x d) 7 x 6.5’
Net weight (approximately) 3,200 lbs
Total Power Consumptions
220V 3KVA/15 amps
440V 3KVA/7.5 amps
Get Your Price from Southern Fabricating Mchy Sales!
