Powder Coating Paint Line, for aluminium or steel profiles and sheets

- Material to be painted : aluminium or steel profiles and sheets

- Medium charge dimension : mm 6500 x 300 x 1500 (H).

- Maximum charge dimension : 8000 x 500 x 1500 mm. In this case the bars holding pieces should be loaded at a double step

- Maximum sheets dimension : mm 5.000 x 1500 x 3.

- Maximum charge weight : kg. 120.

- Theoretical production capacity (maximum) :> 18- bars holding pieces/hour equal to. 864 aluminium profiles (considering profiles having a medium weight of 4 kg.) and the plant equipped with n. 1 application unit

> 30 bars holding pieces/hour equal to. 1440- aluminium profiles (considering profiles having a medium weight of 4 kg.) and the plant equipped with n. 2 application units

- Curing temperature : 180-210° C.

- Curing time : 25 minutes about

- Max. oven air temperature : 230°C.

- Electric power installed : 350 kW approx.

- Power : 400Vac,50Hz,3Ph+hearth

- Thermal capacity installed : 500.000+160.000 Kcal/h
