Baker #C-4-Head, Multi-head Resaw, 6" width x 12" H capacity, 12" width, 13'-2" x 1-1/4" x 0.035" blade, 28" diameter band wheel, (4) 20 HP, 120 FPM, 2026, new
Estimated monthly payment valid upon approved credit.
Description
BAKER C 4-HEAD Horizontal Resaw w/Powered Return6" Wide x 12" high cap. Resaw; standard spring blade tensioning system;Specifications: -- 13'-2" x 1-1/4" x 0.035 blade provides thin kerf savings; quick & easy blade height adjustments. -- Wheels: 28" Dia. CNC machined, dynamically balanced, all-steel band wheels, (4) bolt flange; rough top feed belt combines with opposing side feed rolls and air pressure hold over rolls; idler hold downs . -- (4) 20 HP Total Enclosed Fan Cooled Motors; Thin-kerf technology and the Baker Low Profile Flat Guide System generates up to 60-70% less sawdust and up to 25% more boards, easily out-producing a gang rip. Complete with: -- Hydraulic variable feed speed from 20 to 120 FPM (6 to 36 MPM) with a tank, flow control and remote feed shutoff; powered side feed rolls. Includes: -- Powered conveyor, powered return conveyor, NEMA electrical panel with the starters, motor overload protection, remote start/stop stations.6" x 6" Square dust collection with a 90 adapter chute to a 4" dia. outlet (can be rotated in (4) directions); 600 CFM required for each drop.
Baker Model P.A.Q. Single Head Band Resaw Baker single cut "PAQ" band resaw with return, electric complete with a totally enclosed fan cooled 20HP motor, Nema 12 enclosure, starter, motor overload protection and all is prewired. Machine also complete with a variable speed hydraulic feed system including the pump ...more
