Year: 2007
Width: 72.0
Capacity: .250
Stock # 984426
1 / 4
Click to zoom in
1 / 4
For Sale by G-2000
Surplus Record Dealer Since 2011
Location: Toledo, OH
Contact Evan Yoder
Phone Number: 419...> Show Phone Number 419-597-5495
Let the seller know you found their listing on Surplus Record!
Description
Width Up to 72”
Gauge: .060” to .250”
Separating Load Capacity 600,000 lb
Number of Back Up Flights: 7
Flight Center Distance: 10.75”
Pass Line Height: 48”
Work Roll Diameter: 3”
Work Roll Face: 80”
Number of Work Rolls: 23
Maximum Line Speed: 400 FPM
Power Requirement: 460 Volt 3 Ph 420 Amps (600 amp Disconnect)
| Specifications | |
| Machine Type... | ...Levelers |
| Manufacturer... | ...MACHINE CONCEPTS |
| Model... | ...N/A |
| Year... | ...2007 |
| Condition... | ...Used |
| Max Width of Workpiece... | ...72 inches |
| Separating Load Capacity... | ...600000 pounds |
| Number of Back Up Flights... | ...7 |
| Flight Center Distance... | ...10.75 inches |
| Pass Line Height... | ...48 inches |
| Work Roll Diameter... | ...3 inches |
| Work Roll Face... | ...80 inches |
| Number of Work Rolls... | ...23 |
| Maximum Line Speed... | ...400 inches |
Get Your Price from G-2000!
