For Sale by Perfection Global
Surplus Record Dealer Since 1964
Location: Elk Grove Village, IL
Contact Sales Dept.
Phone Number: 847...> Show Phone Number 847-427-3333
Let the seller know you found their listing on Surplus Record!
Description
Specifications
Equipped With
- Type: Manual
- Table: 6" x 10"
- Table to Spindle Center: 12"
- Longitudinal Table Travel: 12.5"
- Cross Travel: 6"
- Grinding Wheel Capacity: 7" x 0.75" x 1.25"
- Chuck Size: 6" x 10"
- Spindle Speed: 0 RPM - 365 RPM
- Crossfeed Movement Per Rev of Handwheel: 0.100"
- Crossfeed Handwheel: 0.001"
- Crossfeed Fine Feed Knob Grad.: 0.00005"
- Vertical Feed Per Rev of Handwheel: 0.05"
- Standard Handwheel Grad.: 0.0005"
- Fine Feed Knob Grad.: 0.00005"
- Currently Wired: 220 Volts
Equipped With
- Tilting Wheelhead Option (30°)
- Knob for Vertical Axis, 1 HP Taft Pierce Super-Precision Spindle Drive
- Anti-Backlash Nut Assembly for Crossfeed
- Automation Lubrication System
- Saddle Lock
- Replaceable Longitudinal Ways (VEE and Flay Way)
- 240 Volts / 7.2 Amps Adjustable Frequency Inverter Drive
Get Your Price from Perfection Global!
Buyers Who Viewed This Listing Also Viewed:
JUST ADDED!
6" x 12" Harig #612, hand feed surface grinder, 12" longitudinal travel, 6" cross feed, 7" x1/2" wheel, 3450 RPM, 1 HP, coolant tank & pump
