PH# 52480. 36" CLEARANCE L TO R BETWEEN THE SLAB SIDES. 33.75" X 32" NOMINAL BED SIZE. 26" DIAMETER RAM WITH APPROX 20" STROKE. 2000 PSI. APPROX MAX DAYLIGHT IS 49". OPERATOR HEIGHT IS APPROX 48.5". ADJUSTABLE FORTY-FIVE DEGREE GIB GUIDES. 2.25" VERTICAL SLOT IN BOTH SIDES APPROX 5" FROM BACK EDGE. 3" PORT. OVERALL ...more
PRELIMINARY, 500 TONS (PRESSING), 100 TONS (INTERMEDIATE PRESSING), 40 TONS (STRIPPING), 38" STR, 48" DLO, 96" LR X 54" FB BED SIZE, 24" W X 40" H WINDOWS, PLATEN SPEEDS, 65 TO 637 IPM RAPID ADVANCE, 35 TO 325 IPM INTERMEDIATE PRESS, 10 TO 64 IPM, 20 TO 165 IPM SLOW RETURN, 70 TO 663 IPM FAST RETURN, ALLEN BRADLEY ...more
SICMI 551 TON HYD. H-FRAME PRESSMODEL PFC-500… S/N 5648… NEW 2007 TONNAGE. 551STROKE. 19.6"BED SIZE.(F-B x L-R). 47" X 59"DAYLIGHT TO BED.″3-1/4"LOWER RING THICKNESS. 2"SHAFT DIA. 11"ADVANCE SPEED. 1" / SEC.PRESSING SPEED.078" / SEC VOLTAGE 480 VOLT :- ...more
