Description
DETAILED SPECIFICATION
| Operation Type | CNC Control |
| Crowning | Manual |
| Bending Length | 122.10" |
| Distance Between Columns | 102.40" |
| Stroke | 12.20" |
| Open Height | 20.27" |
| Throat | 19.68" |
| Table Height | 38.20" |
| Back Gauge Speed | . |
| X Axis Speed | 23.63 in/sec |
| X. Axis Speed | 23.63 in/sec |
| R Axis Speed | 14.18 in/sec |
| Back Gauge Stroke | 29.54" |
| Rapid Approach Speed | 4.73 in/sec |
| Pressing Speed | 0.43 in/sec |
| Return Speed | 5.67 in/sec |
| Hydraulic Tank Capacity | 77 gallons |
| Horsepower | 30 H.P. |
| Voltage | 220/440V ~ 3 Phase |
| Dimensions (L x W x H) | 191.02" x 120.13" x 118.16" |
| WEIGHT | 32,120 lbs |
Features
Flush Floor Machine
Extremely Rigid Upper Beam
Robust Frame
Hydraulic Fluid
Multiple Hard Chromed Cylinder System
Hydraulic Drive System
Built In Overload Protection
Quick Approach & Return Speeds
Slow Approach In Manual Mode For Tool Alignment
Adjustable Stroke Of Hydraulic Cylinders For Maximum Machine & Tool Flexibility
Fast Cycle Time/Quick Approach & Return Speeds
Manual, Semi-Automatic & Automatic Operation
Ergonomically Designed Control Panel
2 Linear Encoders Located On Each End Of Upper Beam Make Measuring Of The RAM Position
2 Servo Valves Electrically Controlled By DNC (Axes Y1 & Y2)
Choice Of Narrow Or Wide Bed Bolted To The Lower Beam To Allow Flexibility With Tooling
Emergency Stop Palm Button On Foot Pedal Assembly
Key Lock Switch For ON/OFF Power Supply & Selector Of Modes Of Operation
1 Instruction Manual, 1 Programming Manual, 1 Operation & Service Manual
Call For Information & Pricing On Options
19.69" Deep Throat
Standard Wila Manual Crowning
Servo Driven R Back Gauge
Choice Of Cybelec Modeva PAC Or Delem DA-66T Controller
X Axis (Programming Of Flange Dimension/Back Gauge Position)
Y Axes (Y1/Y2) (Programming Of Ram Position Including Tiling For Tapered Bends & X)
1 Set Of Adjustable Punch Holders (Hold American & European Style Forming Punches)
Choice Of Tooling Voucher OR 4 Way Die With Segmented Gooseneck Punch
