For Sale by Sterling Machinery Exchange - New Mach.
Surplus Record Dealer Since 1970
Adam Mattes
626-44...> Show Seller's Phone Number 626-444-0311 Let the seller know you found their listing on Surplus Record!
Description
DETAILED SPECIFICATION
| Operation Type | Semi-Automatic |
| Blade Speed | 85 - 279 fpm |
| Blade Size | 2-5/8" x 0.063" x 344" |
| Material Pass Line Height | 28.3" |
| Coolant Pump Horsepower | 1/4 H.P. |
| Coolant Tank | 58 Gallons |
| Hydraulic Pump Horsepower | 3 H.P. |
| Hydraulic Tank | 22.5 Gallons |
| Horsepower | 15 H.P. |
| Voltage | 230V ~ 3 Phase |
| WEIGHT | 24,251 lbs |
Features
Work Light
NC Control: Ease Of Operation, Multiple Language Capability, Trouble Shooting Prompts
PLC Control For All Electric And Hydraulic Functions
Speed Transmission By Worm Gear & Shaft
Band Door Interlocks
Two Step Full Stroke Vises
Idler Wheel Motion Detector
Blade Breakage/ Stall Motion Detector Shut Off Switch
Multi-Step Full Stroke Vises With Split Front Vise And Variable Vise Pressure Control
Instruction & Parts Manuals On CD
Hydraulic Blade Tension
Carbide Blade Guide With Roller Bearing
Coolant Through Carbide-Faced Saw Guide Inserts
Spring Loaded, Zero Clearance, Coolant Through, Carbide Faced Saw Guide With Lead-In Rollers
Power Driven, Coolant Flushed, Blade Cleaning Wire Brush
Flushing Hose And Auxiliary Coolant Nozzles
Automatic Chip Conveyor
Complimentary DoAll Cutting Fluids Package
Length Setting
One DoAll Bi-Metal Saw Blade
Set Up Tools And Tool Box
Get Your Price from Sterling Machinery Exchange - New Mach.!
