Description
DETAILED SPECIFICATION
| Operation Type | Automatic |
| Capacity | . |
| Bundle Capacity Max. | 25-5/8" x 14-5/8" |
| Bundle Capacity Min. | 14-1/8" x 10-1/4" |
| Blade Speed | 52 - 275 fpm |
| Blade Size | 2-5/8" x 0.063" x 347" |
| Material Pass Line Height | 36.2" |
| Automatic Indexing Lengths | . |
| Single | 15.75" |
| Multiple | 236.2" |
| Remnant Length | Single Piece (Non-Bundle) |
| Coolant Pump Horsepower | 1/4 H.P. |
| Coolant Tank Capacity | 63 Gallons |
| Hydraulic Pump Horsepower | 3 H.P. |
| Hydraulic Tank Capacity | 34 Gallons |
| Horsepower | 15 H.P. |
| Voltage | 230V ~ 3 Phase |
| WEIGHT | 25,350 lbs |
Features
Work Light
NC Control Panel: Touch Screen Control, 20 Job Presets, Multiple Language Capability, Trouble Shooting Prompts, Easy Operation
PLC Control For All Electric And Hydraulic Functions
Infinitely Variable Speed Controlled By VFD
Hydraulic Retractable Shuttle Vise Material Indexer
Band Door Interlocks
Rapid And Creep Speed Index Vise Control
Multi-Step Full Stroke Vises With Split Front Vise And Variable Vise Pressure Control
Spring Loaded, Zero Clearance, Coolant Through, Carbide Faced Saw Guide With Lead-In Rollers
Power Driven, Coolant Flushed, Blade Cleaning Wire Brush
Instruction & Parts Manuals On CD
Hydraulic Blade Tension
Flushing Hose And Auxiliary Coolant Nozzles
Automatic Chip Conveyor
Hydraulically Loaded, Zero Clearance, Coolant Through, Carbide Faced Saw Guide With Lead In Rollers
Blade Breakage/ Stall Motion Detector Shut Off Switch
Blade Shockproof Device
Complimentary DoAll Cutting Fluids Package
Hydraulic System
High Efficiency Transmission
One DoAll Bi-Metal Saw Blade
Set Up Tools And Tool Box
