Pure Air Filtration #SAH-204-V, Horizontal Air Purifier, 4,000 CFM, 3600 RPM blower, 16" x 16" in, 48" x 22-1/2" x 35-1/8" outlet, 7.5 HP, 1800 RPM, 460 V.

Description

Pure Air Filtration 4,000 CFM Horizontal Air Purifier, SAH-204-V

Inventory # 9539

Model: SAH-204-V

S/N: S2015-286-001

Description:

Pure Air Filtration’s Side Access Housing (SAH) system is a horizontal airflow filtration and purification cell system. It provides continuous high-efficiency air purification for low to contaminated air streams ranging in volume from 500 to 32,000 CFM. These systems are configured with refillable or disposable media cartridges in a multitude of configurations to meet specifications and airflow requirements

Specifications:

Airflow: 4,000 CFM @ 5″ Water Column Loss

Blower RPM: 3,600 RPM, Max.

Air Inlet: 16″ x 16″

Air Outlet: 48″ x 22 1/4″ x 35 1/8″ H, 12″ Diameter Hole

Full Load Amps: 18.6 A

Full Load RPM (Motor): 1,800 RPM

Motor: 7.5 HP / 460v / 3ph

Mechanical Specifications:

Dimensions: 56 1/4″ x 27″ x 94 3/4″ H (Not Including Air Outlet)

FOB Our Baltimore, MD Warehouse
