Okuma #Space-Center-MA-600, CNC horizontal machining center, 171 automatic tool changer, 39.3" X, 35.4" Y, 39.3" Z, 12000 RPM, HSK A100, 40 HP, OSP P300MA, Renishaw part probe RMP 600, thru spindle coolant, 2020

OKUMA SPACE CENTER MA 600 4-Axis CNC Horizontal Machine Center. Manufactured in 2020, this used machining center from OKUMA offers precision and reliability. Ideal for enhancing production capabilities in various machining applications. Includes factory 6 auto pallet changer, probing and inspection software.
2020 OKUMA MA-600
SPECIFICATIONS:
Pallet Size - L...................... 24.8"
Pallet Size - W...................... 24.8"
Number of Pallets.................... 6
Pallet Weight Capacity............... 2,640 lb
Pallet Surface to Spindle Center..... 1.96'' - 37.4''
Pallet Center To Spindle Gage Line... 2.7'' - 42.13''
Workpiece Dimensions................. 39.37'' x 39.37'
X - AxisTravel....................... 39.3"
Y - Axis Travel...................... 35.4"
Z - Axis Travel...................... 39.3"
B - Axis Travel...................... .001
Rapid Traverse Rate - X.............. 2,362 in/min.
Rapid Traverse Rate - Y.............. 2362 ipm
Rapid Traverse Rate - Z.............. 2362 ipm
Spindle Speed........................ 12,000 RPM
Spindle Taper........................ HSK A100
Number of Ranges..................... 2
Main Motor........................... 40 hp
Automatic Tool Changer............... 171
Tool Diameter........................ 5.3", 9.4"
Tool Length.......................... 17.7"
Tool Weight.......................... 55 lb
Machine Weight....................... 57,200 lb
Control.............................. CNC (OKUMA OSP P300MA CNC COLOR CONTROL)
Weight............................... 0.00
EQUIPPED WITH:
OSP P300MA CNC COLOR CONTROL
6 AUT0 PALLET CHANGING SYSTEM
ANIMATION, PROGRAM HELP, HI-G, 320 METERS, CYCLE TIME REDUCTION
HELICAL INTERP., DURECT POSITIONING,SKIP FUNCTION, CHANGE WK COORD.
PLAY BACK IMAP, IMAP, HELP, AREA MACHINING
4 AXIS CONTROL, ANGLE 1/10,000 INDEX TABLE B, ADD AXIS NAME B, SSU-R
4 AXIS B FIX, TOUCH SENSOR MOVE
THERMAL COMPENSATION
COOLANT THRU THE SPINDLE, SPINDLE AIR BLOW
FILTRATION UNIT, CHIP CONVEYOR
COOLANT CHILLER UNIT
SYNC. TAPPING
TOUCH SENS. MOVE, TOOL LIFE MANANGEMENT, TOOL DATA 200,
ALL AVAILABLE MANUALS
CHIP CONVEYOR
HIGH PRESSURE COOLANT THRU SPINDLE 1000 PSI
TOOL DATA 200
SHOWER COOLANT/GUN WASH APC SIDE
SYNC. CONTROL Y
VER. BACKLASH
TAPE STORAGE 320M
TOOL DATA 200, APC PALLET WAIT ROTATION, APC SAFETY GUARD, PALLET SI WATCH, ATC AUTO DOOR
SUB-PROGRAM
ADD-PATTERN CYCLE/ POINT CALCULATION
POINT CALC / ADD PATTERN CYCL / HI-CUT PRO / 3D R-SIMULATION
3D R-SIMULATION/ SEQUENCE STOP
COORDINATE CALCULATION/ AREA MACHINING/ COODINATE CONVERSION/ PROGRAM LIMIT/ PLAYBACK (IMAP)/ IMAP
PFC2/WCS2
DNC T1 / COMMON VARIABLE 200 SETS
GRAPHIC IMAP, HI - G, NC OP MONITOR, SERVO LINK NC AXIS, SERVO LINK S AXIS, 4 AXIS B FIX
RENISHAW PART PROBE RMP 600
INVERSE TIME FEED FUNCTION
MACHINING NAVI M-G
