Mazak #QTN-450II, CNC Turning Center, 29.5" swing, 18" chuck, 6.5" bar, Mazatrol Matrix Nexus Control, 2011

29.5” X 22.8” Two Axis CNC Turning Center with Mazatrol Matrix Nexus CNC Control, 50 HP Spindle Motor, 12 Station Block Style Turret, Tail Stock, Collet Chuck, 3 - Jaw Chuck, Tool Setter, Automatic Tool Eye, Sequence Number Comparison STO Function, Y - Axis Control, Overload Detection System, Re-Threading, Parts Catcher and Chip Conveyor
GENERAL SPECIFICATIONS
Max. Swing: 29.5”
Max. Turning Diameter: 22.8”
Main Spindle Bore / Max. Bar Capacity: 7.23” / 6.5”
Tail Stock / Sub Spindle: Tail Stock
Max. Swing Over Cross Slide: 22.8”
Max. Cutting Length: 82.6”
X - Axis Travel (X1,X2,X3): 13.375”
Z - Axis Travel (Z1,Z2,Z3): 82.25”
Y - Axis Travel (Y1,Y2,Y3): ±5.9”
C - Axis Indexing (1, 2): 0.0001
Main Spindle Chuck Size: 18”
Main Spindle Bore Diameter: 7.23”
Main Spindle Max. Bar Work: 6.5”
Main Spindle Speed: 2,000 RPM
Main Spindle HP (Cont. / 30 Min): 50
Rear Chuck Prep: Yes
Turret Positions 1, 2: 12
Turret Rotary Tool Spindle Speed 1,2: 4,000
Turret Rotary Tool HP 1, 2: 10
High Pressure Coolant System: 213 PSI
Rapid Traverse X - Axis: 1181
Rapid Traverse Z - Axis: 1299
Dimensions: 301” X 108” X 106”
Weight: 42,417 Lbs
INCLUDES: Mazatrol Matrix Nexus CNC Control, 50 HP Spindle Motor, 12 Station Block Style Turret, Tail Stock, Collet Chuck, 3 - Jaw Chuck, Tool Setter, Automatic Tool Eye, Sequence Number Comparison STO Function, Y - Axis Control, Overload Detection System, Re-Threading, Parts Catcher and Chip Conveyor

***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***
