KYB #Hydrostar MRH-270, Hydraulic Motor, 3570 PSI, 125, New

KYB Hydrostar MRH-270 TW-1

• Make: KYB
• Model: Hydrostar MRH-270
• Condition: New
• Heavy Duty Model
• LSHT Motor (Low-Speed, High-Torque)
• TW-1
  • T-Type Shaft
  • Tapered and Keyed Shaft
  • SAE 4 Bolt Flange

General Features:

• Speed is Infinitely Variable and Torque Constant Over Entire Speed Range
• Excellent Efficiency Allows Precise Positioning of Driven Equipment
• Rapid Acceleration, Deceleration and Reversing
• Large Main Bearings: Long Life, Allow Heavy Side Load Capacity
  • B10 Life= 5100 Hours (Average Life of Bearings is 20,400 Hours)
• Several Drain Port Locations to Ease Mounting
• Seals Made of Viton
• Commonly Used in Fishing to Forestry, Mining to Marine, Recycling to Shredders, as well as Conveyors and Railroad Equipment.

Specifications

• Displacement Volume: 268.4 in.³/Rev
• Maximum Continuous Pressure: 3570 PSI
• Intermittent Peak Pressure: 4000 PSI
• Maximum Continuous Back Pressure: 350 PSI
• Maximum Intermittent Back Pressure: 1000 PSI
• Maximum Continuous Output Torque: 11648 ft-lbs
• Starting Torque at 3570 PSI: 9550 ft-lbs
• Maximum Continuous Speed: 125 RPM
• Maximum Continuous Power: 225 HP
• Moment of Inertia (GD²): 4354 lb-in.²
• Maximum Fluid Temperature: 175°F

• Shipping Dimensions: 22" Diameter x 23" Long
• Weight: 820 Lbs

• Location: Western Canada
