For Sale by Blumberg Machinery Co
Description
PRODUCT HIGHLIGHTS
- 15 HP Spindle Motor, 12-Speeds
- 4.5” Spindle Through Hole
- Solid Full Length Casting Base
- Spindle Jog Button Control
- One-shot/Auto Lubrication for Apron, Carriage, and Bed Ways
- Multi-position Adjustable Feed Position Stops
- Dual Inch/Metric Calibrated Tailstock Quill
STANDARD ACCESSORIES
- 3-jaw chuck
- Steady rest
- Follow rest
- Thread Chasing Dial
- Carriage Stop
- 4-position tool post
- Coolant system
Capacity | Swing over bed ways | 26” (660mm) |
Swing over cross slide | 17.3” (440mm) | |
Swing over gap | 35” (890mm) | |
Gap length (w/ face plate) | 11.8” (300mm) | |
Bed width | 15.75” (400mm) | |
Distance between centers | 80”/130”/169” (2000/3300/4300mm) | |
Headstock | Spindle hole | 4.5” (115mm) |
Spindle nose camlock | D1-11 | |
Spindle to sleeve taper | MT#7 | |
Spindle bore | 4.5”(115mm) | |
Spindle speed | 12 Steps, | |
Carriage | Cross slide travel | 14.75” (375mm) |
Top slide (compound) travel | 8” (200mm) | |
Feed Box | Thread capacity (inches) | 44, 2 - 56 TPI |
Thread capacity (metric) | 39, 0.5 - 14 MM | |
Leadscrew Diameter | 1.5” | |
leadscrew pitch | 4 TPI | |
Longitudinal feeds | 0.002 – 0.032 IPR | |
Cross feeds | 0.001 – 0.0094 IPR | |
Tailstock | Quill diameter with tang | 3.3” (85mm) |
Quill travel | 6.5” (165mm) | |
Quill taper | MT#5 | |
Power | Main motor | 15 HP |
Coolant pump motor | 1/8 HP | |
Control circuit voltage | 115 V | |
Dimension | Shipping dimension (LxWxH) | 137”/186”/219”x41”x52” |
Weight | Net weight (approx) | 6570/8223/10890 LBS |
Gross weight (approx) | 6900/8554/11332 LBS |
Get Your Price from Blumberg Machinery Co!
