Jet #GHD-20, single spindle drill, 2 HP, 10" spindle to column, 4-1/2" column diameter, 3" quill diameter

SERIAL .............................. 80401204

MODEL ............................... GHD-20

CAST IRON DRILLING CAPACITY ......... 1-1/2"

STEEL DRILLING CAPACITY ............. 1-1/4"

SPINDLE TRAVEL ...................... 4-1/2"

SPINDLE TO COLUMN ................... 10"

SPINDLE SPEEDS ...................... (12) 60 TO 3000 RPM

COLUMN DIAMETER ..................... 4-1/2"

QUILL DIAMETER ...................... 3"

SPINDLE TAPER ....................... #3 MT

TABLE WORK SURFACE (T-SLOTTED) ...... 21-3/4" X 19-1/2"

BASE WORK SURFACE (T-SLOTTED) ....... 15-1/4" X 13"

SPINDLE TO TABLE (MAXIMUM) .......... 30-1/2"

SPINDLE TO BASE (MAXIMUM) ........... 44-15/16"

TABLE TRAVEL ........................ 25-1/2"

COLUMN ROTATING TABLE ............... YES

WORK TABLE CAPACITY ................. 275 LBS

HORSEPOWER SPINDLE MOTOR ............ 2
