For Sale by Carolina Machinery Sales
Surplus Record Dealer Since 2021
Location: Monroe, NC
Contact Ralph Viegelmann
Phone Number: 704...> Show Phone Number 704-288-1904
Let the seller know you found their listing on Surplus Record!
Description
WORKING CAPABILITY
Case length: 2,500 mm (98-3/8”) maximum, 250 mm (9-7/8”) minimum
Case depth: 700 mm (27½”) maximum, 250 mm (9-7/8”) minimum
Case height: 1,400 mm (55-1/8”) maximum, 150 mm (11¾”) minimum
MACHINE SPECIFICATIONS
Vertical and horizontal pressure beams with variable pressure capacity
Positioning speed (fixed): 25 mm/s (4.9 fpm) and 50 mm/s (9.8 fpm)
UTILITY REQUIREMENTS
Operating voltage: 460v, 3PH, 60 Hz
Amperage service: 8.7 amps @ 460 volts
Control voltage: 25 volt
Total connected load: 4 kW
Vertical and horizontal pressure: 15 kN (3,372 lbs/force)
Height of work platform: 300 mm (11¾”)
AMBIENT TEMPERATURE
Operating range 5°-35°C (min/max), 41°-85°F (min/max)
FOUNDATION REQUIREMENT
Concrete thickness (minimum): 180 mm (7”)
Floor space required (length): 4,000 mm (157½”)
Floor space required (width): 750 mm (29½”)
Floor space required (height): 2,500 mm (98½”)
Case length: 2,500 mm (98-3/8”) maximum, 250 mm (9-7/8”) minimum
Case depth: 700 mm (27½”) maximum, 250 mm (9-7/8”) minimum
Case height: 1,400 mm (55-1/8”) maximum, 150 mm (11¾”) minimum
MACHINE SPECIFICATIONS
Vertical and horizontal pressure beams with variable pressure capacity
Positioning speed (fixed): 25 mm/s (4.9 fpm) and 50 mm/s (9.8 fpm)
UTILITY REQUIREMENTS
Operating voltage: 460v, 3PH, 60 Hz
Amperage service: 8.7 amps @ 460 volts
Control voltage: 25 volt
Total connected load: 4 kW
Vertical and horizontal pressure: 15 kN (3,372 lbs/force)
Height of work platform: 300 mm (11¾”)
AMBIENT TEMPERATURE
Operating range 5°-35°C (min/max), 41°-85°F (min/max)
FOUNDATION REQUIREMENT
Concrete thickness (minimum): 180 mm (7”)
Floor space required (length): 4,000 mm (157½”)
Floor space required (width): 750 mm (29½”)
Floor space required (height): 2,500 mm (98½”)
Get Your Price from Carolina Machinery Sales!
