Herfraga #SM-214, automatic tuna packing machine, large formats, 20-40 cans/minute, 5" - 8-7/16" can diameter, up to 5-1/8" can height, 1-7 kg

Specifications:

HEIGHT	1.90 m
INCLUDED	2.00 m
USEFUL WIDTH	0.00 m
LENGTH	4.30 m
WEIGHT	2200 Kg
MAKE	HERFRAGA
PRODUCTION	30 CANS/MIN
MODEL	SM-214
MAX FORMAT (MM)	214
MIN FORMAT (MM)	127
CONTROL PANNEL	INCLUDED
CAN DIAMETER	214 MM
MAX HEIGHT OF JAR IN MM	130 mm
FORMAT	RO-2600

Description:
With this continuous automatic machine, which is fed directly with the product to be filled, packing is carried out in one or two cuts, at a rate of 20 to 40 cans per minute and with a minimum of personnel, representing a great saving in manpower.
Specially designed for large formats, i.e. for cans up to 214 mm. in diameter and a maximum height of up to 130 mm. The containers can be cylindrical, oval or rectangular in shape.
Due to its production in formats from 1 to 7 kg, a great reduction in packaging costs is obtained, and the machine allows a total utilisation of the article to be packaged and an unbeatable presentation.
Like its counterparts in our varied range, this machine is built on a sturdy base and top quality materials are used in its construction, with the parts in contact with the fish being made of stainless steel and food plastics.
The central lubrication system allows for the lubrication of the machine.
Its simplified design and easy access to all its parts makes cleaning and maintenance quick and easy.
TECHNICAL CHARACTERISTICS
-Shape of the container to be packed: round, oval or rectangular.
-Production: from 20 to 50 cans/min.
-Diameters to be packed: from 127 to 214 mm.
-Height: up to a maximum of 130 mm.
