Description
SPECIFICATIONS
EQUIPPED WITH
Hydraulic Clamping. Index Plates. Change Gears. Coolant.
This machine is being offered cleaned, and cycled. It is being offered with a 30-Day Return Privilege and may be inspected under power.
| Longest Cone Distance | 11" |
| Largest Pitch Angle | 90° |
| Smallest Pitch Angle (without chamfering or burring attachments) | 45° |
| Largest Pitch Diameter:-1 to 1 Ratio | 15.5" |
| Largest Pitch Diameter:-12 to 1 Ratio | 22" |
| Largest Pitch (diametral) | 1.5 DP |
| Maximum Face Width | 4" |
| Index Range(number of teeth) | 31 to 78 |
| Feed (seconds per tooth) | 5 to 40 |
| Diameter of Tapered Nose (large end) | 6-7/8" |
| Length of Tapered Nose | .75" |
| Taper Per Foot | .5" |
| Diameter of Hole Through | 2" |
| Spindle Nose to Center Line of Machine | 4.5" to 8" |
| Cutter Diameter | 9", 12", 18" |
| Cutter Speeds | 100 to 150 |
| Main Motor | 10 HP, 1800 RPM |
| Floor Space | 84" x 103" |
| Weight | 18,500 lbs |
EQUIPPED WITH
Hydraulic Clamping. Index Plates. Change Gears. Coolant.
This machine is being offered cleaned, and cycled. It is being offered with a 30-Day Return Privilege and may be inspected under power.
