Description
DMC DL 22LA
SPECIFICATIONS:
Swing................... 21.65"
Machining Length........ 21.26"
Max. Turning Length..... 21.26"
Max. Turning Diameter... 15.35"
X-Axis.................. 8.27"
Z-Axis.................. 22.83"
Chuck Size.............. 8"
Bar Capacity............ 2.56"
Spindle Bore............ 2.99 in
Spindle Nose............ A2-6
Power................... 25 hp
Max RPM................. 3,500 RPM
Turret Stations......... 12
Tailstock............... Yes
Dimensions.............. 116.54" x 64.96" x 74.8"
Weight.................. 9,700 Lbs
EQUIPPED WITH:
Fanuc 0i-T CNC Control
X/Z Box Way
Automatic (Servo) Tailstock
Programmable Quill
Chip Conveyor
Bar Feeder Interface
Tool Presetter
Parts Catcher
SPECIFICATIONS:
Swing................... 21.65"
Machining Length........ 21.26"
Max. Turning Length..... 21.26"
Max. Turning Diameter... 15.35"
X-Axis.................. 8.27"
Z-Axis.................. 22.83"
Chuck Size.............. 8"
Bar Capacity............ 2.56"
Spindle Bore............ 2.99 in
Spindle Nose............ A2-6
Power................... 25 hp
Max RPM................. 3,500 RPM
Turret Stations......... 12
Tailstock............... Yes
Dimensions.............. 116.54" x 64.96" x 74.8"
Weight.................. 9,700 Lbs
EQUIPPED WITH:
Fanuc 0i-T CNC Control
X/Z Box Way
Automatic (Servo) Tailstock
Programmable Quill
Chip Conveyor
Bar Feeder Interface
Tool Presetter
Parts Catcher
