Columbia #FL100, low level, full case palletizer, 5-12 cases per minute, with 12 capacity empty pallet magazine that accommodates pallets from 40" x 40" to 48" x 48"

Columbia Model FL100, Low level, full case palletizer rated from 5 to 12 cases per minute and number of pallets per hour – depending on materials and application. Case size range: up to 22″ in Length; 16″ in Width; 18″ in Height. Pallet load capacity: up to 48″ in Length; 48″ in Width; and 65″ in Height with skid and Weight capacity: up to 600 lbs per tier and 3000 lbs per load. Equipped with 12 capacity empty pallet magazine that accommodates pallets from 40″ x 40″ to 48″ x 48″, with powered roller case in feed conveyor, orientation, and layer former, pallet loading section with pusher bar and discharge conveyor. Control panel has A/B PLC and safety guarding.

Slip Sheet Feeder Available At Additional Cost

OAD: 188″ L x 192″ W x 120″ H Palletizer

80″ L x 58″ W x 84″ H Pallet Magazine
