Click to zoom in
For Sale by Machinery Solutions Inc
Surplus Record Dealer Since 1999
Location: Lexington, SC
Contact Jason A.
Phone Number: 803...> Show Phone Number 803-359-7000
Let the seller know you found their listing on Surplus Record!
Description
SPECIFICATIONS: TRAVEL: X-axis: 19.7" Y-axis: 17.7" Z-axis: 16.1" Distance between table top to spindle nose: 26" TABLE : Work area size: 25.6" x 17.7" Maximum loading capacity: 551 lbs. Table surface: T slotted SPINDLE: Spindle speed IPM motor: 16 - 16,000 RPM Tapping speed: 8,000 RPM Spindle taper: 7/24, #30 Taper FEED RATE: Rapid traverse X, Y & Z-axis: 2,755 IPM Cutting feed rate: 0.04-787 IPM ATC: Tool storage capacity: 27 Tool shank type: MAS-BT30 Pull stud type: (BT30) MAS-P30T-2 Maximum tool diameter: 4.9" Maximum tool length: 9.8" Maximum tool weight: ( 176 lbs. total in magazine): 7.7 lbs. Tool selection: Random Path Tool Change time: (tool-to-tool in seconds) (chip-to-chip in seconds) 0.9 / 2.4 MOTORS: For IPM spindle: 13.41 / 9.8 HP For axis feed X, Y & Z-axis: 1.74 HP Z-axis thrust: 2005 ft-lbs. POWER SOURCE: Power supply: 200V-230V, 3-Ph. +- 10% 50/60Hz Power capacity KVA for IPM (max): 18 (37) Working air pressure MPa: 0.4-0.6 (4~6kg f/cm2 ) Required air flow L/min: 180 MACHINE DIMENSIONS: Machine height: 99.9" Floor Space required: 58.9" x 122.1" Machine weight: 6,129 lbs.
Get Your Price from Machinery Solutions Inc!
