42" BLANCHARD HIGH-POWER DRY-BASE VERTICAL-SPINDLE ROTARY SURFACE GRINDER Serial No 13871, Model 22HD-42 42" BLANCHARD HIGH-POWER DRY-BASE VERTICAL-SPINDLE ROTARY SURFACE GRINDER Serial No 13871, Model 22HD-42 EQUIPPED WITH: 42" Diameter Magnetic Chuck w/Variable Neutrofier 75 HP Spindle Motor (Optional) Dry Base Design 23" Vertical Range 22" Segmented Grinding Wheel w/(5) Segments Automatic Lubrication CATALOG SPECIFICATIONS: Magnetic Chuck, Diameter 42" Swing Between Coolant-Guards 48" Magnetic Chuck Work Load Capacity 3000 LBS Grinding Vertical Range, Maximum 23" Grinding Wheel Speed 672 RPM (6) Chuck Speeds, Range 6 to 33 RPM Spindle Motor, Horsepower 75 HP Chuck Rotation Motor 3 HP Overall Dimensions, L x W 11'8" x 7' Overall Height 10'1" Weight, Approximately 14500 LBS F.O.B. OUR WAREHOUSE
THE BLANCHARD 22HD-42 IS A HIGH-POWER, GEARED-HEAD VERTICAL SPINDLE ROTARY SURFACE GRINDER DESIGNED FOR HEAVY-DUTY INDUSTRIAL APPLICATIONS. THIS MACHINE S A 42-INCH DIAMETER ELECTROMAGNETIC CHUCK AND A 22-INCH DIAMETER SEGMENTED GRINDING WHEEL, PROVIDING A MAXIMUM WORK SWING OF 48 INCHES INSIDE THE WATER GUARDS. IT IS ...more
Chuck Dia.: 42 inches Spindle (Horz/Vert): vertical Grinding Wheel Dia.: 22 inches GEARED HEAD HIGH HP DESIGN, 22" Grinding Wheel Diameter, 42" Magnetic Chuck (7/16" Chuk Life), 48" Swing Inside Water Guards, 24" Vertical Range(to be verified), 75 HP Geared Head Main Spindle, Pick-Feed Type of Down Feed ...more
Chuck Dia.: 42 inches Spindle (Horz/Vert): vertical Power: No Attached horsepower Swing: No Attached inches Under Wheel: No Attached inches Table Speeds: No Attached Grinding Wheel Width: No Attached inches Table Motor Horsepower: No Attached horsepower Grinding Wheel Dia.: 22 inches CNC Control: No Attached Type of ...more
Rebuilt 22D-42 Blanchard Grinder, (subject to buyer verification):, Subject:22D-42 Blanchard Remanufacture–, I am pleased to provide you with a quote foraremanufactured newlyrebuilt 22D-42Blanchard Grinder This Grinder has received a complete rebuild to address the feed tables, wiring, ways, mag control, and ...more
