For Sale by Yoder Machinery Sales
Surplus Record Dealer Since 1960
Location: Holland, OH
Contact Sales
Phone Number: 866...> Show Phone Number 866-692-8933
Let the seller know you found their listing on Surplus Record!
Description
SERIAL .................................. 11617MODEL ................................... 22-42TABLE CHUCK DIAMETER .................... 42"MAXIMUM WORK SWING ...................... 48"MAXIMUM WORK HEIGHT ..................... 24"TABLE SPEEDS ............................ (6) 6 TO 33 RPMPOWER DOWNFEED RANGE .................... .004 TO .080 IPRSEGMENTED GRINDING WHEEL DIAMETER ....... 22"SWING-AWAY GRINDING WHEEL DRESSER ....... YESMICROMETER CALIPER ATTACHMENT ........... YESLUBRICATION SYSTEM ...................... TRABONELECTRO-MAGNETIC TABLE CHUCK CONTROLS ... YESCHUCK LIFE .............................. 3/8"CONVEYOR IN BASE ........................ YESCOOLANT ................................. YESGRINDING SPINDLE MOTOR .................. 50 HORSEPOWER
Get Your Price from Yoder Machinery Sales!
