For Sale by Mid Atlantic Machinery
Description
Robust steel base structure, powder painted with bright and smooth finishing.
Robust head structure welded. A unique piece of structural steel.
Patented Hydraulic system for a fine regulation of down feed and cutting pressure for any kind of material.
Electronic speed variator 5.3 HP; 460V; speed range 49-328 ft/min.
Miter cutting -45°/+60°; saw head rotation through conical bearings independent from the plans for piece support.
Swing Arm Console with Display to control Blade Speed, Cutting Height, Piece Counter, Blade Load.
Digital Angle integrated and visualized on the front display.
Powered blade brush.
Led working light.
Laser Light.
Sensor for monitoring blade rotation.
Load sensor for monitoring blade tension.
Potentiometer to memorize cutting height and possibility to perform middle cuts.
Eccentric roller for short piece cutting.
Wide Plans for piece support for a comfortable and practical cutting area.
Complete coolant equipment of 13.2 Gal. tank with electro-pump 3ph. inside the basement.
Measuring device L = 20 Inch with height regulation.
Large chips container for easy cleaning.
Bimetal blade 12’ 6 1/2” x 1 1/4” x .042
