60" x .187" Braner, turret slitting line with 72" x 10k Stamco packaging, 40000 lb.

Manufacturer - Braner
Type - Turret Head Slitting Line
Year of Manufacture - 1993
Material - Low Carbon, HRPO, Cold Rolled Bare, Galvanized, Coated
Max Coil Weight - 40,000#
Coil Width - 62"
Strip Thickness Range - 0.012" - 0.187"
Coil OD - 72"
Coil ID Range - 20" - 24"
Shear Strength - 50,000# & 60,000#
Slitter Arbor Diamter - 8"
Number of Heads - 2
Knife Size - 11" Min - 13" Max
Spacer Size - 10" Diameter
Slitter Motor - 100 HP DC, 1150/2550 RPM
Recoiler Motor - 100 HP DC, 850/2550 RPM
Line Speed - 0 - 900 FPM (Low & High Speed Capable)
Power - 460 V, 3 PH, 60 Hz
Line Direction - Left to Right
72" x 10,000# Stamco Packaging Line
Manufacturer - Stamco
Type - Turntable Packaging Line
Max Coil Weight - 10,000#
Max Coil OD - 72"
Coil ID Range - 16", 20", 24"
Max Stack Height - 36" (Including Pallet)
Entry Conveyor Passline - 36 5/8"
Exit Conveyor Passline - 18 5/8" (After Stacking)
Max Skid Turntable Weight - 15,000#
Turntable Rotation - 360 Degrees Continuous Rotation
Braner Slitting Line Components:
4-Arm Entry Turnstile
L-Shaped Coil Car
Mandrel Uncoiler w/ Holddown Arm
Hydraulic Peeler Table
Articulating Pinch Rolls
Side Guides
Automatic Gauge Guide W/ Coil Position Indicator
Crop Shear
Turret Slitting Head
Crossover Table/Looping Pit
Scrap Winders
Drag Pad Tension Stand
Exit Thread Table
Separator Roll
Deflector Roll
Mandrel Recoiler W/ Pushoff
Exit L-Shaped Coil Car
Exit 4 Arm Turnstile
Electrics, Operators Stand, Self Contained Hydraulics and Controls
Stamco Packaging Line Components:
Downlayer
20' Conveyor
6' 6" Coil Scale
7' 11' Banding Table
Stacking Unit
(6) Six Station Lazysusan Turntable
6' 6" Skid Conveyor
5' 11" Skid Scale
Electrics, Operators Stand, Self Contained Hydraulics and Controls
