44 Ton, Durma #E4020, CNC press brake, 6.7' overall, 64.9" between housing, 6.3" stroke, 13.78" throat, 4-Axis, DA-51, 2008

44 TON CAPACITY
80.7" BED
64.9" BETWEEN FRAMES
177 IPM APPROACH SPEED
21 IPM BENDING SPEED
118 IPM RETURN SPEED
6.3" STROKE
13.78" THROAT
15.85 GALLON OIL TANK
5 HP
Compact 4-axis CNC system for press brakes
DA-51
Everything under control
The DA-51 press brake controller offers all basic CNC functions incl. angle programming of the Y-axis, controlling up to 4 axes. The front panel layout with the
bright LCD display
guarantees every user-friendly and easy to program controller. For part programming it provides the user programming space for 500program lines where each program can contain
up to 25 bends
. All bend parameters are orderly listed on one page. For each program there is one extra page available to specify a.o. tooling, material properties and stock count. The unique
“push button page”
structure gives a direct access to programs in memory and guarantees
quick and easy programming of a product .With the test bend
teach-in function
,the press brake utilization will be more efficient due too less programming and less test time. The basic machine control functions areY1-Y2 and X axis, optionally a second back gauge axis can be used as R/Z or X2-axis.
DA-51 featuring:
•One page programming R-axis, Z-axis or X2-axis optional•Crowning control•Panel based housing•Large memory base Tool library Servo, frequency inverter and AC control
