For Sale by Alma Machinery Co-Columbia TN
Surplus Record Dealer Since 1960
Location: Columbia, TN
Contact Ken King
Phone Number: 615...> Show Phone Number 615-369-7788
Let the seller know you found their listing on Surplus Record!
Description
| CAPACITY | 400 TON | STROKE | 14" | max die height | 24" (SDAU - OVER BOLSTER) | BED AREA | 60" X 42" (RL X FB) | SPEED | 25 - 45 SPM (VARIABLE) | slide adjustment | 14" (MOTORIZED) | slide area | 60" RL X 42" FB (T-SLOTTED) | bolster | 10" TH X 60" RL X 42" FB (T-SLOTTED) | WINDOW SIZE | 25" FB X 25" H (APPROX) | DIStance between uprights | 61" | distance floor to bed | 32.5" (over 7.5" h isolators) | CLUTCH: | AIR CLUTCH & BRAKE. | ELECTRICS: | approx. 40 hp 1750 rpm MOTOR & existing press control | APPROX. DIMENSIONS: | 17' H X 10' RL X 9' FB | APPROX. WEIGHT | 80,000 LBS. | Equipped With | AIR COUNTERBALANCES, TIE ROD FRAME CONSTRUCTION, AUTOMATIC OIL LUBRICATION SYSTEM, FLOOR MOUNTED BASE when mounted on isolators | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
Get Your Price from Alma Machinery Co-Columbia TN!
Buyers Who Viewed This Listing Also Viewed:
400 Ton, Blow #SC2-400-60-42, straight side double crank, 14" stroke, 24" Shut Height, 14" adj., 60" x42" bed, 25-45 SPM, 28" windows, OmniLink Control, air clutch & brake, 1997
Seller: D & D Industries Inc
Location: Monclova, OH
Mfr: Blow
Model: SC2-400-60-42
Year: 1997
14" STROKE, 24" SHUT HEIGHT OVER BOLSTER, 14" SLIDE ADJUSTMENT (MOTORIZED), 60" X 42" BED, 60" X 42" RAM, 25-45 SPM, 28" WINDOWS, OMNILNK CONTROLS, AIR CLUTCH, AIR BRAKE, AIR COUNTERBALANCE, 153" X 105" X 209" TALL APROX., 115,000 LBS APROX.
400 Ton, Blow #SC2-400-60-42, straight side double crank press, 14" stroke, 24" Shut Height, 25-45 SPM, air clutch & brake, 1997
Seller: Timco Inc
Location: Columbia, TN
Mfr: Blow
Model: SC2-400-60-42
Year: 1997
BLOW 400 TON SSDC PRESS, STOCK# 14434J, MDL# SC2-400-60-42, S/N# SDG-400-431-97, NEW 1997, CAPACITY 400 TON, STROKE: 14", SHUT HEIGHT OVER BOLSTER : 24", SLIDE ADJUSTMENT 14" (MOTORIZED), BED SIZE: 60" LR X 42" FB, SLIDE AREA 60" LR X 42" FB, SPEED 25-45 SPM, WINDOWS 28", EQUIPPED W/, LINK OMNILINK PRESS CONTROLS, AIR ...more
400 Ton, Fagor, 4-point straight side double crank press, 14" stroke, 26" -41.15" Shut Height, 144" x96" bed, 10-20 SPM, 1999
Seller: National Machinery Exchange
Location: Newark, NJ
Mfr: Fagor
Year: 1999
400 TON FAGOR STRAIGHT SIDE DOUBLE CRANK PRESS, MANUFACTURER - FAGOR, TONNAGE - 400, TYPE - 4 POINT STRAIGHT SIDE DOUBLE CRANK, YEAR - 1999, BED AREA - 144" X 96", SHUTHEIGHT - 26" - 41.15", STROKE - 14", WINDOW WIDTH - 84", SPM - 10-20, BOLSTER PLATE THICKNESS - 5.78", MOTOR - 184 Kw, AIR CUSHIONS - NO.
JUST ADDED!
400 Ton, CCI #S2-400-120x48, straight side press, 14" stroke, 36" Shut Height, 10" adj., 120" x 48" bed, 15-30 SPM, 30.5" x 38" windows, 60 HP, 1986
Seller: Presses for Industry
Location: Detroit, MI
Mfr: Cci
Model: S2-400-120X48
Year: 1986
PRELIMINARY Model: #S2-400-120x48New: 1986Capacity: 400 TonStroke 14"Shut Height: 36" (To The Bolster)Slide Adjustment: 10"Bed Area: 120"LR x 48"FBSlide Area: 120"LR x 48"FBSpeed: 15 - 30 SPM (variable)Windows: 30.5" Wide x 38" HighFloor Standing DesignAir Clutch & Brake on BackshaftAir Counterbalances8.5" ...more
400 Ton, Verson #S2-400-132-60T, straight side double crank press, 14" stroke, 34" Shut Height, 16" ram adjustment, with feeder
Seller: Perfection Global
Location: Elk Grove Village, IL
Mfr: Verson
Model: S2-400-132-60T
Capacity: 400 TonStroke Length: 14"Shut Height: 34"Bed Area (L-R x F-B): 132" x 60"Ram Adjustment: 16"Window Width: 24", Feeder.
