KARD MODEL FTP-30. F TO B BETWEEN THE POSTS IS 16"; OVERALL L TO R IS 60"; NOMINAL BED SIZE IS 32.5" X 32". MAX DAYLIGHT OF APPROX 30". CYLINDER IS APPROX 6" BORE WITH A 5.5" DIAMETER ROD AND 22" MAX STROKE. FULLY GUIDED WITH 8" BUSHINGS ON 3" DIAMETER POSTS. APPROX 34" OPERATOR HEIGHT. BED AND SLIDE HAVE T-SLOTS. ...more
CAPACITY. 50 TON, STROKE OF RAM. 16", MAX DAYLIGHT OPENING. 42", SHUT HEIGHT. 28", MIN RAM FACE TO BED. 26", BED WORKING SURFACE. 36" F-B X 52-1/2" L-R, DISTANCE BETWEEN THE POSTS. 26" F-B X 42" L-R, RECTANGULAR CUT OUT IN BED. 15" F-B X 20" L-R, BED HAS 2 T-SLOTS IN CENTER. 4" OFF CENTER, DRILLED & TAPPED RAM ...more
Used 30 ton Brown inline vertical trim press. Model T-354V, serial #15892, new 2015. Has 20" x 61" platen. Reported good up to 54" maximum sheet size. Rated up to 145 strokes per minute, 4.5"-13.5" stroke. Includes control panel., 2015 BROWN T354V.
Central Eng.\Hannifin 100 Ton 4 Post Die Trim Press, Model: M518-00, S#: 0194, Date Mfg.: 04-98, Manufactured by Goshen Rubber Central Engineering, Designed by Hannifin, Capacity: 100 Ton, 4 Post down acting, Bed area: 32" x 32", Platen size: 40"W x 21.5" between posts, Shut height & stroke: 18", 5" Dia. Hydraulic ...more
Used Brown T-310 Thermoformer for Sale. This unit has a window size opening of 12.25″ x 40″ with a stationary window side, and a maximum stroke of 13.5″. The trim press is rated at 30 tons. Electrical requirements are 480v. Drive is a Reliance Electric SP500 VS variable speed drive, which appears to ...more
