280 Ton, Piranha #280-13P, cnc press brake, 13.4' overall, 141.5" between housing, 17.7" open, 25 HP, 8.5" stroke, Delem DA-66T Control, 2017

Listing Information
ID # 699235
Stock # LA
Brand PIRANHA
Model 280-13P
Type Press Brakes
Control CNC (Delem DA-66T)
Year 2017
Condition Used - Good
Return Policy as-is
Location Wisconsin, United States

Description Used 2017 Piranha 280-13P CNC Press Brake

Specifications
Tonnage 280 T
Type HYD
Overall Length 161.4"
Between Housings 141.5"
Stroke 8.5"
# Axis 6
Dimensions 197" L x 83" W x 110" H
Weight 37200

Equipped With
Delem DA-66T Control,
Synchronized precision hydraulic brake system with programmable Y1/Y2 rams,
EasyCrown integrated hydraulic crowning system for accurate bends,
Fiessler AKAS-LC laser safety curtain system,
European/American reversible precision tooling clamps,
Manual and linear-guided front sheet supports,
High-speed precision back gauge (X, R, Z1/Z2) – up to 6+1 axis,

Spec Sheet
Pressure 280 TONS
Length of worktable 161.4 IN
Die Rail Height 3.15 IN
Distance between uprights 141.5 IN
Ram stroke 8.5 IN
Max open height (with die rail without clamps) 17.7 IN
Throat depth 16.1 IN
CNC axis w/Delem Control Up to 6+1 Axis Configuration
Ram Speed Approach 283 IPM
Work 21 IPM
Return 248 IPM
Repeatability 0.0004 IN
Back Gauge X Stroke 19.7 IN
Work piece size 0-38.5 IN
Max running speed 708 IPM
Re-position 0.001 IN
Overall Dimensions L 197 IN
W 83 IN
H 110 IN
Oil Capacity 135 Gallons
Motor 25 HP
Machine weight 37,200 LBS

***CALL Louie at 847-627-6009 for more details or a quote***
