Description
Specifications
- Main Slide
- Tonnage Capacity: 200 Ton
- Bolster Area (L-R x F-B) 20.1" x 28.7"
- Slide Area (L-R x F-B) 21.7" x 18.9"
- Daylight: 47.2"
- Opening in Upright: 20"
- Stroke Length: 21.7"
- Unloaded Stroke Speeds (Up / Down): 472 IPM / 472 IPM
- Pressing Speeds (20-100 Tons) 82 IPM
- Pressing Speeds (100-200 Tons) 35 IPM
- Lifting Power: 30 Ton
- Slide Core (Servo Valve Control)
- Pressure Capability: 1.5 - 30 Ton
- Stroke Length: 3.9"
- Head Diameter: 2.7"
- Pressing Speed: 106 IPM
- Slide Inner (Proportional Valve Control)
- Pressure Capability: 10 - 30 Ton
- Stroke Length: 8.7"
- Head Diameter: 1.4" - 4"
- Bed Core (Servo Valve Control)
- Pressure Capability: 3 - 60 Ton
- Stroke Length: 2.8"
- Head Diameter: 2.2"
- Bed Inner (Servo Valve Control)
- Pressure Capability: 10 - 100 Ton
- Stroke Length: 8.7"
- Head Diameter: 1.3" - 3"
