Manufacturer: Federal
Model: G1-200-54-30
Year: 1995
Ton: 200
Stroke: 6.0
Shut Height: 22.00
Stock # 8156
1 / 5
Click to zoom in
1 / 5
For Sale by Alma Machinery Co-Columbia TN
Surplus Record Dealer Since 1960
Location: Columbia, TN
Contact Ken King
Phone Number: 615...> Show Phone Number 615-369-7788
Let the seller know you found their listing on Surplus Record!
Description
| Capacity | 200 Ton | stroke | 6" | shut height to bed | 22" sdau | bed area | 54" X 30" (RL X FB) | Speed | 35 spm | SLIDE AREA | 36" x 24" (RL X fb) (t-slot) | SLIDE ADJUSTMENT | 8" (air motor) | bolster size | 4.75" x 54" X 30" (H X RL X FB) (T-slot) | Distance between uprights | 32" | distance floor to bed | 38" | THROAT DEPTH | 16" | clutch | FEDERAL air clutch & Brake | electrics | 25 hp 1150 rpm 240/480v-3-60 motor & existing link ss-501 press control | approx. dimensions | 14' H X 8' RL X 9' FB | Approx Weight | 48,000 LBS | Equipped With | fixed base gap press, steel frame construction, lincoln grease lubrication system, air cushion in base, floor standing, single back geared, single end drive, complete with air tank and flywheel guards | Note | __ |
|---|---|
| Location | This Used Press is Located in Our Columbia, TN Warehouse |
