Angle Plates, 119" x 23 1/8" x 59 1/2" Base Drilled & Tapped, Face Dimensions 23 1/8" x 119 1/2", Base Dimensions 23 1/8" x 59 1/2", Drilled and Tapped Holes, Symmetrical, Holes 18", 12", & 6" On Center, Preliminary - Subject to Verification.
1.- These Cast Iron angle plates are used as a work-holding devices to clamp and hold workpieces in the vertical position and as a vertical reference for inspection and tooling purposes in machining processes such as shaping, planing, boring, milling, grinding and drilling, etc., 2.- The types of angle plates are ...more
STOCK NO. ET-4716, FABRICATED 24” X 96” HIGH T-SLOTTED ANGLE PLATE, Make:, Model:, T-SLOTTED FACE DIMENSIONS: 24″ W X 96″ HIGH X 3-1/4″ THICK, BASE DIMENSIONS: 24″ W X 36″ DEEP X 3-1/2″ THICK, BASE HAS A KEY SLOT, FACE DRILLED AND TAPPED BY 4 HOLES ACROSS X 17 HOLES ...more
, Giddings & Lewis 15′ (180″) x 36″ x 36″ Angle Plate, Pair, on Lower Set:, 2-G&L: 36″ Wide x 96″ Tall x 36″ Deep (Bottom), 2-G&L 36" Wide x 94" Tall x 36" Deep (Top Blocks), Mounted to a T-Slotted Floor Plate: 12′ Long x 36″ Wide x 5″ Thick ...more
