Description
SPECIFICATIONS
EQUIPPED WITH
| Workpiece Range | : |
| Outside Diameter | 0.8 - 12.5 mm / 1/32" - 1/2" |
| Thread Pitch | 0.4 - 1.5P / 60 - 6 TPI |
| Max. Length | 30 (40) mm / 1-1/8" (1-9/16") |
| Roll Dies | : |
| Rolling Speed | 40 rpm |
| Max. Outside Diameter | 100 mm / 3.93” |
| Inside Diameter | 50.5 mm / 1.98” |
| Max. Width | 30 (40) mm / 1.18” |
| Max. Center Distance of Die-Spindle | 130 mm / 5.11” |
| Min. Center Distance of Die-spindle | 90 mm / 3.5” |
| Output (Pcs/Min.) | 20 - 40 |
| Motor | : |
| For Spindle | 1HP, 3 Phase, 60 Cycle, 220 Volt |
| For Coolant Pump | 1/8 HP |
| Machine Body | : |
| Floor Space | 30” x 36” |
| Approx. Weight | 395 kg |
EQUIPPED WITH
EQUIPPED WITH:
Push Button Start/Stop. Cam Operated Rolling Slide. Adjustable Skew. Coolant Pump and Tank. Manual Lubrication. Work Support.
