9 Results
36" x 36" Portage, Rotary Layout Machine
G-2000 | Toledo, OH
Category: Layout Tables
Seller: G-2000
Location: Toledo, OH
Mfr: Portage
MODEL: A, SERIAL: 50664, 36" X 36" TABLE, Machine Type.Layout Machines Manufacturer.PORTAGE Model.N/A Year.N/A Condition.Used.
49" x 190" x 6" Portage, slotted cast iron construction layout table
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF PLATE. 190", WIDTH OF PLATE. 48", THICKNESS OF PLATE. 5-3/4", GRID LINE CENTERS. 10", GRID LINES. 3/8" WIDE X 1/4" DEEP, THROUGH HOLES. 10, SOLID CONSTRUCTION. YES.
50" x 70" x 5-3/4" Portage layout table, fabricated stand, leveling stand
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF PLATE. 70", WIDTH OF PLATE. 50", PLATE THICKNESS. 6-1/4", HEIGHT ON STAND. 32", SLOTS RUNNING 70" DIMENSION. 10, SLOTS RUNNING 100" DIMENSION. 7, 4 LEVELING HOLE IN TOP. YES, FABRICATED STAND. YES, LEVELING SCREWS. YES, 16 OF THESE PLATES IN STOCK CAN BE BOLTED TOGETHER TO MAKE A LARGE PLATE.
50" x 70" x 6" Portage layout table, fabricated stand, leveling screws, #73498
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF PLATE. 70", WIDTH OF PLATE. 50", PLATE THICKNESS. 6", SLOTS RUNNING 70" DIMENSION. 10, SLOTS RUNNING 50" DIMENSION.
50" x 70" Portage, steel layout table
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF TABLE. 70", WIDTH OF TABLE. 50", TABLE HEIGHT. 6-1/2", WEBBED CAST CONSTRUCTION. YES, HEIGHT OF TABLE ON STAND. 31", LAYOUT SURFACE SECTIONED INTO 10" SQUARES.
Get email updates for newly added Layout Tables
Layout Tables (also known as layout inspection tables or surface plates) are flat, durable surfaces used for measuring, marking, and inspecting workpieces during manufacturing processes. Commonly used in industries like metalworking, automotive, and aerospace, these tables provide a stable reference for precise layout work and quality checks. Layout tables ensure accuracy and consistency, making them essential for high-precision machining and assembly tasks.
73" x 144" Portage, key slotted layout table with stands, resurfaced & excellent
Roberts Machinery Sales | Ferndale, MI
Category: Layout Tables
Seller: Roberts Machinery Sales
Location: Ferndale, MI
Mfr: Portage
73" x 144" LAYOUT TABLEWITH TWO STANDSSTOCK NO. 6445, OVERALL SIZE: 73" x 144", TABLE THICKNESS: 8", KEY SLOTS: 10" SPACING, KEY WIDTH:.400", TABLE FLATNESS002 TIR OVERALL, CONSTRUCTION:, HEAVY DUTY RIBBED, 14 KEY SLOTS ON WIDTH x 7 KEY SLOTS ON LENGTH, TWO LEVELING STANDS, ROBERTS MACHINERY SALES LTD., 930 E. ...more
100" x 240" x 7" Portage layout plate, grid lines, #74115
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF PLATE. 240" (20'), WIDTH OF PLATE. 100", THICKNESS OF PLATE. 7", CAST IRON CONSTRUCTION. YES, OVERALL HEIGHT. 10", GRID LINES ON PLATE. YES, CENTER DISTANCE BETWEEN LINES. 7-7/8" SQUARE, (18) LEVELERS. 3 ROWS OF 6, (4) LEVELERS-THROUGH TOP ADJUSTMENT. YES, (14) LEVELERS-SIDE (EDGE) ADJUSTMENT. YES ...more
120" x 96" x 10" Portage layout table, 3/8" x 1/4" layout grooves, 10" groove centers
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF PLATE. 120", WIDTH OF PLATE. 96", PLATE HEIGHT. 10", LAYOUT GROOVES. 3/8" X 1/4", GROOVE CENTERS. 10".
173" x 78" x 9" Portage layout plate, cast iron construction, #76744
Yoder Machinery Sales | Holland, OH
Category: Layout Tables
Seller: Yoder Machinery Sales
Location: Holland, OH
Mfr: Portage
LENGTH OF PLATE. 178", WIDTH OF PLATE. 78-3/4", HEIGHT OF PLATE. 9", GROOVES WIDTH DIRECTION. 21, GROOVES LENGTH DIRECTION. 10, GROVE CENTER., CAST IRON CONSTRUCTION. YES, SEE STOCK 76745 TO MAKE PLATE 178" X 157".
