Yaskawa Motoman, GP280L, 6-Axis Articulated Robot, 280 Kg Payload, 3114 mm Reach, YRC1000 Controller, 2022

Estimated monthly payment valid upon approved credit.

Request Formal Quote

The 2022 Yaskawa Motoman GP280L is a six-axis industrial robot designed for high-payload handling and extended-reach applications. It features a maximum payload capacity of 280 kg, a horizontal reach of 3,114 mm, a vertical reach of 3,552 mm, and a repeatability of ±0.01 mm. The robot is controlled by the YRC1000 system and has a weight of 2,380 kg. Technical specifications include internal user I/O cables with 24 conductors plus ground and a 3/8-inch internal user air line connection. Power requirements are 380-480 VAC with a 7.5 kVA rating. Range of motion for the axes is S ±180°, L +90°/-45°, U +15.5°/-120°, R ±360°, B ±125°, and T ±360°. Maximum axis speeds are rated at 110°/sec for S, 90°/sec for L and U, 125°/sec for R and B, and 205°/sec for T. The unit is engineered for applications such as dispensing, material cutting, material handling, machine tending, and press tending. Its design includes a streamlined upper arm to minimize interference with fixtures and high moment of inertia ratings to accommodate large parts.
