Description
Specifications
- Manufacturer: Hy-G
- Year: Aprrox. 1984
- Approximate Specifications Based on Model Year:
- Model: 30 inch
- Capacity (max.): 35 YPH (23 Cy/Hr) of minus 5mm ore.
- Centrifugal Force: 70 G's applied to slurry at 405 rpm
- Typical Recovery: 94% - 98% of plus 325 mesh free placer gold
- Inlet Slurry Density: 15% to 40% soilds by weight
- Inlet Slurry Volume: 530 GPM @ 20% soilds
- Feed Size: minus 5mm (3/16" maximum)
- Inlet Feed Pipe: 5" diameter with Victaulic groove
- Outlet Tailing Pipe 8" diameter with Victaulic groove
- Horsepower: 20 Hp
- 480 volt
- 3 phase
- 60 Hz
- Clean Water: 210 GPM @ psi, 4" pipe inlet (backpressure water)
- Tails Lining Abrasion Resistant alloy steel
- Electrical: None - owner must provide
- Operation: Manual valves and concentrate discharge ports
- Operating Cycle: Empty once every 24 hours of continuous operation or once per daily shift
- Clean Out Cycle: Manually wash out concentrate. Aprrox. time 12 min
- Size of Unit: 5'-6 high by 4'-2 square base
- Weight: 2,850lbs
- Location: Western USA
