Hafele #Futura-250, Hinge Boring Mach., 80 mm bore w/ 650 ft.lb. @ 90 psi, 3.5 million 3" strokes, 1.5 HP, 1990

$2,930 USD

Request Formal Quote

RAFIX - Futura 250: Hinge Boring & Inserting Machine with 1-1/2 HP MotorSpecifications -- High-quality air cylinder (80 mm bore with 650 ft. Lbs of pressure @ 90 PSI) rated for 3-1/2 million 3" strokes.A skilled Operator can bore & insert in (3 - 4) seconds. -- Features: (2) Types of boring depth adjustment: Drawbar style for quick and easy adjustment and a solid stop adjustment for the changing of door thickness applications. This allows changing of the door thickness and still bore the same depth without adjustment. -- Fixed table with: Adjustable back rail to control the tab location. -- Enclosed cutting area for better chip removal with blow off nozzle to assist in chip evacuation and adjustable 2" & 4" vacuum hookup. -- Pneumatic drilling unit with push button control. -- Includes: Adjustable cutting speed control; indicator light; reset thermal circuit breaker; emergency stop button; drill & insert buttons (2-hand activation for Operator safety); rotary switch for pair of pneumatic holddown clamps; 600 mm ruler & (4) flip stops.
