Automatic empty container depalletizer, vacuum sweep type, 27' 11" L, 6.8 HP, modular outfeed conveyor

Specifications:

HEIGHT	2.60 m
INCLUDED	2.20 m
USEFUL WIDTH	1.43 m
LENGTH	8.50 m
WEIGHT	0 Kg
MAKE	FERLO
MADE OF	STAINLESS STEEL
CONTROL PANNEL	INCLUDED
POWER	5 KW/ 6.8 HP
INCLUDED	MODULAR CONVEYOR OUTPUT BELT
INCLUDED	4 ENGINES

Description:
Vacuum depalletiser for different formats, automatic cycle by cycle.
Features:
- Pallet lifting system using side chains for handling from a suitable working height.
- Synchronised movements.
- Push by means of rodless cylinders, depalletising by sweeping containers.
- Automated pallet entry and exit.
- Ladder with integrated control panel for operation from a suitable working height.
- Three exit belts at different speeds, to place the containers one by one.
- Loading chains to accumulate 2 full pallets on standby and one in operation.
- Separator accumulation drawer located according to layout.
- Automatic pallet exit from the front of the machine.
- Automatic empty pallet accumulator with a capacity of 8 units.
- Suitable for working with pallets up to 2,300 mm in height.
