DMG, Mori Deckel Maho #DMU-80P-hi-dyn, 30 automatic tool changer, 31.5" X, 27.6" Y, 23.6" Z, 6300 RPM, 2005

5-AXIS MACHINING CENTERS DECKEL MAHO DMU 80P hi-dyn SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: 2005 DMG MORI DECKEL MAHO DMU80P hi-dyn 5Axis Universal Machining Center: *May be inspected in plant under power by appointment* HEIDENHAIN MillPlus IT CNC Control with electronic handwheel & Ethernet -DESIGN CONCEPT- This is a UNIVERSAL machining center meaning it is two machines in one: both a vertical AND horizontal machining center. The universal milling head on this machine is automatic and programmable. It can be swivelled in 6 seconds from vertical to horizontal, and in combination with the rotary swivel table makes 5-sided 5-axis machining in a single set up possible. Setup time is reduced, the need for multiple setups is eliminated and accuracy and precision are improved. The P Series machines are intended for fully automatic manufacturing of highly complex workpieces in a single set up. Ideal for both small and large batches with the high production components including high pressure CTS (Coolant Thru The Spindle) and chip conveyor. -WORKING RANGE- Maximum part size 31.5" (800 mm) diameter x 23.6" (600 mm) high x 1,323lbs -NC SWIVEL ROTARY TABLE- Swivel angles To spindle -45 degrees, from working spindle +30 degrees -AUTOMATIC UNIVERSAL MILLING HEAD- Automatic swivel from horizontal to vertical in approximately 6 seconds. The auto swivel head makes this machine 2 machines in one because both vertical and horizontal machining is possible with one workpiece clamping. Together with the NC Swivel Rotary table 5-Sided, 5-Axis simultaneous machining is possible with one workpiece clamping. -GEARED SPINDLE- Number of gear steps 2, acceleration/deceleration from 20-6,300 rpm 3 sec -FEED DRIVES- -30 POSITION TOOL CHANGER- Maximum tool diameter with no neighbouring empty pockets 4.33" (110 mm) Chip-to-chip time CAT40 Approximately 16 seconds vertical, 7.5 sec horiz -HEIDENHAIN GLASS SCALES X/Y/Z AXES DIRECT PATH MEASURING SYSTEM- -HEIDENHAIN ROTARY ENCODERS B/C AXES DIRECT PATH MEASURING SYSTEM- -EXTERNAL FLOOD COOLANT PUMP ON OUTSIDE OF SPINDLE- Pump output external jets flow rate 10.6 gallon/minute (40 l/min), 1.5 bar -INTERNAL HIGH PRESSURE COOLANT SUPPLY THRU THE SPINDLE (40 BAR CTS)- -EQUIPPED WITH- Fully enclosed protection cabin Chip conveyor BLUM Laser Tool Measuring of tool length and diameter RENISHAW MP10 infrared parts measuring touch probe Auto swivel milling head that swivels from vertical-horizontal & viceversa Tool breakage monitoring Original machine parameters on CD, diskette and paper print out Original accuracy test chart from the factory in Germany Electrical schematics, operator manual, programming manual
