DMG, Mori Deckel Maho #DMF-250 linear, 30 automatic tool changer, 98.4" X, 36.2" Y, 32.2" Z, 18000 RPM, 2004

5-AXIS MACHINING CENTERS DECKEL MAHO DMF 250 linear SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: One used 2004 DMG DECKEL MAHO DMF 250 linear 5-Axis Machining Center: Machine made in Seebach, Germany -CONTROL- HEIDENHAIN iTNC 530 3D path control with electronic handwheel -WORKING RANGE- -FEED DRIVES- Linear path measuring systems resolution 0.00039" (0.001 mm)HH glassscales -COOLING LUBRICANT SUPPLY; (COOLANT OR AIR)- Switch over from cooling lubricant/air, time of nozzles Approx 10/4 secs -RIGID TABLE- -NC SUB-TABLE (C OR A AXIS)- -SPINDLE- -B-AXIS CONTROLLED SWIVEL MILLING HEAD- The swivelling angle is axially controlled and can be continuously positioned. The position can be hydraulically clamped during machining. Traversing range of spindle nose across table: The swivelling radius of the spindle nose is 12.79" (325 mm) with a minimum vertical position of 2.95" (75 mm) above table. 5-axis machining is possible with the NC sub-table. -30 POSITION TOOL MAGAZINE- -EQUIPPED WITH- HEIDENHAIN infrared parts measuring probe TS 641 BLUM Laser tool measurement system for tool length and diameter. Measurement at nominal speed. Laser mounted on right side of table. Swarf conveyor, discharge height 33.4" (850 mm) Coolant thru the spindle (CTS) with paper type filter: 247 PSI (17 bar) pressure 6.07 gallon/minute (23 liter/minute) flow rate 158 gallon (600 liter) tank Includes rotating clear-view windows on front doors Includes blocking air for linear measuring systems Required air pressure 87.02 psi (6 bar) recirculating roller guide ways Electrical cabinet with heat exchanger longitudinal and shutter-type for the vertical guide ways, inclined surfaces are arranged for the best possible swarf removal APPROXIMATE WEIGHT 54013#
