50 Ton, Neff #DF, C-frame hydraulic press, 10" stroke, Koyo DO-05RD Direct Control, 15 HP, 1992

SERIAL ............................. 9423

MODEL .............................. DF

YEAR NEW ........................... 1992

CAPACITY ........................... 50 TONS

STROKE ............................. 0" TO 10" MAXIMUM

OPEN HEIGHT ........................ 24"

CLOSED HEIGHT ...................... 14"

AREA OF BED ........................ 36" X 21"

AREA OF RAM ........................ 34" X 16"

THROAT DEPTH ....................... 10"

RAM DIAMETER ....................... 7"

FULL-CYCLE STROKES PER MINUTE ...... 16

RAM PRESSING SPEED ................. 160 IPM

PRESSURE ADJUSTMENT ................ YES

FAST & SLOW PRESS .................. YES

KOYO DIRECT CONTROL ................ DO-05RD

ELECTRIC FOOT PEDAL ................ YES

LIGHT CURTAINS ..................... YES

MOTOR .............................. 15 HORSEPOWER
