13" x 18" Hydmech #S-20A, Automatic Horizontal Pivot Band Saw, 14'10" x1" blade, 330 SFM, 5 HP, VFD, digital read out

Description

Hydmech 13″ x 18″ Automatic Horizontal Pivot Band Saw, S-20A

Inventory # 10065

Model: S-20A

S/N: 80505675F0

Specifications:

Capacity:

Rectangular:

@ 90°: 13″ x 18″

@ 45°: 13″ x 10 3/4″

@ 30°: 13″ x 7 3/4″

Round:

@ 90°: 13″

@ 45°: 12″

@ 30°: 8 1/2″

Blade Size: 14′ 10″ x 1″

Blade Speed: 75 – 330 SFM

Coolant Tank Capacity: 12 Gallons

Work Load: 5,000 lbs.

Table Height: 31″

Motor: 5 HP / 240v / 3ph

Standard Features:

Easy swing, heavy-duty cast iron saw head that can swing up to 60° in one direction

Cast iron shuttle features automatic multi-indexing up to 27″ in a single stroke – powered by ball screw and stepper motor

5 HP VFD – true direct blade drive – no belts/pulleys

On-demand hydraulics save energy

The blade chamber separates material from the cut part, extending blade life

Cast iron band wheels

Automatic PLC, touch screen control, programmable up to 100 jobs with 20 in queue

Replaceable blade brush

Robust steel base

Easy to read angle scale with angle locking mechanism

Cast iron guide arms mounted on linear rails is adjustable for proper spacing

Easy access electrical panel

Full capacity, full stroke hydraulic material vises

Out of stock switch

Mechanical blade tensioning with digital readout

Hydraulic positive down feed of the sawing head

Pre-set, replaceable carbide guide inserts

Safety door interlocks

Flood coolant with wash down hose

Laser light

Work light

Variable vise pressure

Mechanical Specifications:

Dimensions: 93″ x 86″ x 52″ H

Weight: approx. 3,800 lbs.

New Replacement Cost: $39,900.00

FOB Our Baltimore, MD Warehouse
