Vacuum Dryers

1995 Bepex Solidaire Drying System. Model: SJS-8X4. Materials of construction include 304 L stainless steel. Jacket MAWP: 150 PSIG at 365F. Jacket MDMT: 70F at 150 PSIG. s (2) Bailey Fischer Porter digital displays, Reliance Electric motor: hp, 1725 rpm, 208-230V, 60 Hz, 3 phase, and a Dodge Tigear speed reducer. The ...more

Used Bepex Solidaire Dryer, Dimensions: 16" dia. x 10' long, Model: SJS 16-10, National board: 244, Serial: SJS-82000729, Year: 1982, Jacket pressure: 165 psig @ 370°F, Location: South USA.

Used 10 cu. ft. Buflovak rotary vacuum dryer, 304 stainless steel construction, 24" diameter x 48" long chamber, rated vacuum -15mm Hg, carbon steel jacketed for 50 PSI at 650 F, 8" top opening, 10" center bottom outlet with manual discharge valve, chain and sprocket driven with 3 hp 230/460 volt ...more

Used Buss Rotary Vacuum Dryer, 141 cu. ft. working capacity, 304 stainless steel construction, 5' diameter x 12' long rated full vacuum internal, cored paddle and shaft agitator rated 5 Kg/centimeters squared (71.12 PSI), jacketed for 5 Kg/centimeters squared (71.12 PSI), jacketed on full straight side ...more

Used 107 cu. ft. DeDietrich Glass Lined Double Cone Dryer Shell Only, rated 40 PSI full vacuum internal, jacketed for 90 PSI, Serial No. 30896, National Board No. 1662. AS IS.

One (1) 10 cu. ft. Gemco Slant Cone Rotary Vacuum Dryer 10 cu. ft. working capacity, slant cone dryer 316L stainless steel polished interior Carbon steel dimple jacket Internal finish is polished and welds are ground smooth National Board stamp 1925 Internal Pressure Rating: Full vacuum @ 350 F Jacket Pressure Rating: ...more

Vacuum dryer, Gemco, 30 cu. ft., stainless steel product contact parts, jacketed for hot water. Unit complete with 5 HP, 220 volt drive to gearbox. Unit mounted on stand complete with rotary joints for vacuum and hot water controls to jacket. Unit has been slightly imploded and would be suitable for slight vacuum and ...more

Used 1 cu ft Gemco double cone vacuum dryer, 316L stainless steel construction, approximately 18" diameter shell, rated 30 psi and full vacuum at 350 f internal, jacketed for 30 psi at 350 f, rated 100#/cu ft max material density, 11" feed opening with cover, 4" outlet, with 1.5 hp, 575 volt, xp motor ...more

Used Patterson Double Cone Vacuum Tumble Dryer, 29 cu. ft. working capacity, 304 stainless steel construction, rated 15 psi and full vacuum at 300 f internal, carbon steel jacket rated 15 psi at 300° f, 16" feed opening with cover, 8" discharge, on stands with 2 hp, 220/440 volt xp variable speed motor ...more

Vacuum conical dryer, 300 liter (10 cubic feet) capacity, manufactured by Lee Industries, Model 300LU, 316 stainless steel vessel, rated for 50 PSI at 300 degrees Fahrenheit, internally. Includes 304 stainless steel jacket, rated for for 100 PSI at 338 degrees Fahrenheit. Pan measures 30" diameter X 26" straight side ...more

Product s, Used Maguire Vacuum Dryer, Model VBD-1000, New in 2016, Maximum Throughput.1000 lbs./hr., Heating Hopper Volume.1200 lbs, Vacuum Vessel Volume.400 lbs., Retention Hopper Volume.400 lbs., Max. Temperature.370F, Process Heater.40 KW, Blower.10 HP, 600 scfm, Compressed Air Pressure.80 psi, Compressed Air ...more

Used 10 cu. ft. Patterson-Kelley double cone vacuum dryer, 304 stainless steel construction, rated full vacuum internal, jacketed for 50 PSI, 40#/cu. ft. max. material density, 14" feed opening with cover, 8" discharge with butterfly valve, on stands with 2 HP 220/440 volt motor drive, 25 RPM shell speed ...more

Petterson-Kelley 20 cu. ft. Twin shell, v-type vacuum dryer with stainless steel product contact parts. Unit has carbon steel jacket rated 30 PSI @ 250 deg. F. Dryer is rated vacuum internal, complete with 5 HP Reeves vari-drive; motor with brake to chain sprocket drive, designed for 9.5 to. 95 RPM. Dryer is complete ...more

Used 20 cu ft Abbe double cone vacuum dryer, stainless steel construction.

Used 53"dia. X 12'L Stainless Steel Rotary Drum Vacuum Dryer, Vacuum drum is a 53" diameter cylinder 12' long, 14'-4" total drum length., End cones on the cylinder are tapered to 18" end openings with covers., Drum Wall: 0.171" cylinder; 0.141" cone, Internal Baffles: Cylinder ...more

, used Stokes Vacuum Tray Dryer model 338F-6. Chamber is Approx. 30" wide x 40" ht. x 40" deep. S/N 73078. Sold as is., STOKES 338F-6, Type. VACUUM.

Used 12 sq ft Stokes vacuum shelf dryer, model M-900-338, stainless steel construction, (3) 24" x 24" shelves rated 50 psi at 500 f, rated full vacuum internal, 4.8" shelf spacing, with temp control skid with heat exchanger and circulation pump, serial# 73683, new 1996.

Used Strong Scott (Bepex) Solidaire dryer, Stainless steel, 2' diameter x 12' chamber, Requires 15 hp drive, Location: On Site at Perry (Hainesport, NJ - USA).

Oven, vacuum dryer, manufactured by T-M Vacuum Products in Riverton, NJ. Unit is electrically heated, stainless steel chamber measures 12" diameter x 14" front to back with swing opening door with o-ring seal. Unit is rated for full vacuum internal, missing some controls, mounted on stand. Unit operates on 208 volt ...more
