Epoxy Lined Tanks in Illinois

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Cds

Model: CVS121620

Year: 2009

Product s, Used 20' CDS Vacuum Sizing Tank, 16" Wide x 12" Deep 16" Width, 18 Water Outlets, 18 Vacuum Outlets, 4 Kw Water Ring Vacuum Pump, 3 Hp Process Pump, With Inline Filter, Plate And Frame Heat Exchanger, Comes With Circulation Tank 42" +/- 3" Centerline, On Casters 460/3/60, 20 AMPS New In 2009 S/N: ...more

10 Photos

CDS #CVS121620, 16" width x 12" D, vacuum sizing tank, 2009

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Cds

Model: CVS121620

Year: 2009

Product s, Used 20' CDS Vacuum Sizing Tank, 16" Wide 16" Width, 18 Water Outlets, 18 Vacuum Outlets 6 Sections Consisting Of: (1) 36" Primary Section, (4) 48" Sections, (1) 12" Section 7.5 HP Marathon Vacuum Pump 3 HP Baldor Recirculation Pump Control Panel 130" L x 15" W x 14" H Holding Tank Plate & Frame ...more

CDS, 25' flood/spray tank, 4 HP recirculation pump

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Cds

Product s, Used 25' CDS Flood/Spray Tank 12" x 12" Cross Section 8" Diameter Bulkhead Openings 2 Spray Bars Per Section 42" +/- 3" Centerline Approx. 4 HP Recirculation Pump Starter Panel Plate & Frame Heat Exchanger 21' L x 18" W x 14" Stainless Holding Tank Manual Height, Forward/Back, And Side To Side ...more

10 Photos

Conair #MSBHI-16-12, Vacuum Sizing Tank, 22" width x 20" H x 16' L, 14" opening, 12 port vacuum, 2.5/7.5/7.5 HP pumps, manual adj, 4 sections

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Conair

Model: MSBH1 16-12

Product s, 16' Long Conair Vacuum Sizing Tank, Model MSBHI-16-12 22" W x 20" H Cross Section, 14" Bulk Head Opening Right To Left Operation 12 Port Vacuum Manifold 7.5 HP Sterling Vacuum Pump 7.5 HP G&L Water Pump Additional 2.5 HP Vacuum Pump Located At End Of Tank 36" L x 20" W x 10" Stainless Steel Holding Tank ...more

Fruil Filiere, vacuum calibration table, vacuum pumps & controls

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Fruil Filiere

Product s, Used 15' Friul Filiere Vacuum Calibration Table, (3) Pompetravaini Vacuum Pumps 177" x 11" Table, 19' x 23" Water Trough 48" x 13" x 20" Water Reservoir (2) Vacuum Manifolds with 8 Ports, Each with PSI Gauge Motorized Movement.

10 Photos

Get email updates for newly added Epoxy Lined Tanks

Epoxy Lined Tanks (also known as epoxy-coated tanks) are storage vessels coated with an epoxy resin to provide corrosion resistance and protect the tank from chemical or environmental damage. Commonly used in industries like chemical processing, water treatment, and food storage, they are ideal for storing corrosive liquids and chemicals. Epoxy lined tanks are essential for ensuring the durability and longevity of tanks in harsh conditions, offering reliable and safe storage solutions.

Kiwex #SJ65/25SC, Vacuum Sizing Tank, 20" width x 26' L, 18 water out, 18 vacuum out, 460 V.

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Kiwex Machinery

Model: SJ65/25SC

Product s, Used 26' Kiwex Vacuum Sizing Tank, Model SJ65/25SC 20" Width, 18 Water Outlets, 18 Vacuum Outlets 460 Volt KWX210826SC-2.

Plastic Pipe & Supply Inc., HDPE Storage Tank, 500 gallon

Revelation Machinery | Chicago, IL

816-33... (Show) 816-330-2138

Category: Epoxy Lined Tanks

Seller: Revelation Machinery

Location: Chicago, IL

Mfr: Plastic Pipe & Supply Inc

Year: 1900

Make: Plastic Pipe & Supply Inc., Model: 500 Gallon, Year: 1900, Machine Location: Connecticut, – 500 Gallon Storage Tank, – Previously Holding Ionized Water.

TEC Polymer, Vacuum Sizing Tank, 10 gauge Stainless Steel, 16" width x 12" D x 12' L, 5 chambers, 7.5 HP pump, 1-yr warranty

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Model: 12

Product s, New TEC Polymer Vacuum Sizing Tank 10 To 14 Week Lead Time From Date Of Deposit *Size 12 ft. long vacuum tank, 12 in. deep, 16 in. wide with a 1 ft. air wipe on discharge end. *10 Ga. Stainless steel vacuum tank with 3/16 bulk heads, chambers to be one 24 in. starter with a main body of three 3 ft. vacuum ...more

TEC Polymer, Vacuum Sizing Tank, 14" width x 12" D x 14' L, 4 chambers, 3 axis movement, 2/3/7.5 HP pumps, 100 plate heat exchanger (2 available)

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Model: 20

Product s, NEW 14' TEC Polymer Vacuum Sizing Tank 14' Long 14" Wide 12"" Deep 3 Compartments, (1) 24" Starter Section, (3) 48" Sections 3 Axis Movement, 12" Front To Back, 3" Side To Side, 12" Up And Down (1) 7.5" HP Vacuum Pump For Main Tank (1) 3 HP HP Vacuum Pump For Starter Section (1) 2 HP Recirculation ...more

TEC Polymer, Vacuum Sizing Tank, 14" width x 12" D x 14' L, 4 chambers, 3 axis movement, 2/3/7.5 HP pumps, 100 plate heat exchanger

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Model: 20

Product s, 4 Compartments, (1) 24" Starter Section, (3) 48" Sections 3 Axis Movement, 12" Front To Back, 3" Side To Side, 12" Up And Down (1) 7.5 HP Vacuum Pump For Main Tank (1) 3 HP Vacuum Pump For Starter Section (1) 2 HP Recirculation Pump 100 Plate Heat Exchanger Stainless Steel Holding Tank Options Include: ...more

TEC Polymer, Vacuum Sizing Tank, 14" width x 12" D x 20' L, 6 chambers, 3 axis movement, 2/3/7.5 HP pumps, 100 plate heat exchanger

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Model: 20

Product s, NEW 20' TEC Polymer Vacuum Sizing Tank 20' L x 14" W x 12" Deep 6 Compartments, (1) 30" Starter Section, (5) 42" Sections 3 Axis Movement, 12" Front To Back, 3" Side To Side, 12" Up And Down (1) 7.5 HP Vacuum Pump For Main Tank (1) 3 HP Vacuum Pump For Starter Section (1) 2 HP Recirculation Pump 100 ...more

3 Photos

TEC Polymer, Vacuum Sizing Tank, 14" width x 12" D x 22' L, 6 chambers, 3 axis movement, 2/3/7.5 HP pumps, 100 plate heat exchanger

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Model: 22

Product s, NEW 22' TEC Polymer Vacuum Sizing Tank 22' Long 14" Wide 12" Deep 6 Compartments, (1) 30" Starter Section, (5) 46.8" Sections 3 Axis Movement, 12" Front To Back, 3" Side To Side, 12" Up And Down (1) 7.5" HP Vacuum Pump For Main Tank (1) 3 HP HP Vacuum Pump For Starter Section (1) 2 HP Recirculation ...more

TEC Polymer, Vacuum Sizing Tank, 16" width x 12" D x 20' L, 12" x 8" openings, 3/7.5 HP pumps, 18 vacuum & 6 water manifold ports, 42" centerline, right to left, casters

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Product s, Used 20' Tec Polymer Vacuum Sizing Tank 16" W x 12" Cross Section 24" Primary Vacuum Section 12" W x 8" H Bulkhead Openings 7.5 HP Travaini TRSE 40-100/C/RX Vacuum Pump 3 HP Water Recirculation Pump 18 Port Vacuum Manifold 6 Port Water Manifold 42" Centerline 460/3/60 Right To Left Operation Motor ...more

TEC Polymer, Vacuum Sizing Tank, 20" width x 12" D x 145" L, 8" x 17" opening, 2 x 72" chambers, 12 water & 12 vacuum manifolds, 3/5/10 HP pumps, Nema 4X enclosure

Arlington Machinery | Lake Zurich, IL

Category: Epoxy Lined Tanks

Seller: Arlington Machinery

Location: Lake Zurich, IL

Mfr: Tec Polymer

Product s, New TEC Polymer Vacuum SIzing Tank Configuration: 145" L x 20" W x 12" Deep 17" x 8" Tank Opening 304 Stainless Steel 1/8" Thick 3/16" End Caps (2) 72" Vacuum Chamber Configuration 12 Water Manifolds, 12 Vacuum Manifolds Aluminum Lid (Choice of 4 Doors Free Upgrade) 2 Vacuum Pumps (5HP, 10HP) 1 ...more

Mixing tank and heat exchange system, 250 gallon, 150 psi, system mounted on Stainless Steel frame

Frain Industries | Carol Stream, IL

630-62... (Show) 630-629-9900

Category: Epoxy Lined Tanks

Seller: Frain Industries

Location: Carol Stream, IL

250 Gallon, 304 stainless steel, mixing tank and heat exchange system. Vessel dimensions: 42" diameter with a 42" straight wall, dome top and slant bottom with (1) 3½" OD / 3" ID tri-clamp discharge with 18" ground clearance. an Enerquip 7"OD x 63" long tube in tube heat ...more

5 Photos

Horizontal tank, 80 gallon

OEM Air Compressor Corp. | Maywood, IL

773-52... (Show) 773-523-8200

Category: Epoxy Lined Tanks

Seller: OEM Air Compressor Corp.

Location: Maywood, IL

Horizontal tank, 120 gallon

OEM Air Compressor Corp. | Maywood, IL

773-52... (Show) 773-523-8200

Category: Epoxy Lined Tanks

Seller: OEM Air Compressor Corp.

Location: Maywood, IL
